COMP Cams 7228-1 Race Street Conical Valve Spring 1.290" OD 1.800" Installed Height

Manufacturer

Picture for manufacturer COMP Cams

Part Number

7228-1
13 reviews
Sale Price

$35.95

In Stock (7)

delivery box

Usually delivered within 2 days

Check out with

ApplePay
Authorize Seller Badge
No Hassle Returns

No Hassle Returns

Live-in-stock inventory

Live-in-stock inventory

Fitment guaranteed

Fitment guaranteed

Product Details

The COMP Cams 7228-1 is a single Race Street conical valve spring engineered with a revolutionary tapered design that delivers outstanding high-RPM stability, superior heat dissipation, and longer service life compared to traditional cylindrical or beehive springs. Sold individually, this spring is an ideal upgrade for street/strip performance builds using hydraulic roller and solid flat tappet camshafts.

The conical geometry naturally dampens spring harmonics, reducing the risk of valve float and extending component life under demanding conditions. Precision-formed from superior-quality spring steel, each spring is shot-peened and finished with a rust-preventative coating for long-lasting durability.

Key Specifications:

  • Spring Style: Conical (single)
  • Outer Diameter: 1.020" (top) / 1.290" (bottom)
  • Inner Diameter: 0.650" (top) / 0.920" (bottom)
  • Installed Height: 1.800"
  • Seat Load: 136 lbs @ 1.800"
  • Open Load: 412 lbs @ 1.170"
  • Spring Rate: 438 lb./in.
  • Coil Bind Height: 1.125"
  • Quantity: 1 spring

Key Features:

  • Conical tapered shape eliminates harmonics and extends spring lifespan
  • Improved heat dissipation over traditional cylindrical designs
  • Shot-peened surface for enhanced fatigue resistance
  • Compatible with COMP Cams 1774-series tool steel retainers
  • Suitable for hydraulic roller, solid flat tappet, and mild solid roller camshaft applications

Valve springs are one of the most critical components in any performance valvetrain. Always verify installed height, check for coil bind clearance (minimum 0.060" at full lift), and confirm retainer-to-seal clearance before final assembly. For best results, pair with a matched COMP Cams retainer and apply COMP Cams Valvetrain Assembly Spray (Part #106) during installation.

Products specifications

Number of Springs

1

Outer Bottom Spring Inside Diameter

0.918

Coil Bind Height

1.125

Seat Height

1.8

Seat Pressure

136

Spring Rate

440

Compatible .570" Guide Diameter Spring Seat

4677-1

Compatible Shims

4753

Compatible Retainer

788-1

Damper

No

Outer Top Spring Inside Diameter

0.662

Outer Top Spring Outside Diameter

1.03

Outer Bottom Spring Outside Diameter

1.286

AMAZON ASIN

B00N6LQEHI

Valve Spring Series

Race/Street

Prop 65

WARNING: Cancer and Reproductive Harm P65Warnings.ca.gov

C.A.R.B. Exempt for Foreign Vehicles Manufactured Before 1967?

Yes, but must meet tailpipe emission standards for year of vehicle.

C.A.R.B. Exempt for On-Road Vehicles?

Yes

C.A.R.B. Exempt for Racing and Off-Road Only Vehicles?

Yes, but must be a race/competition only vehicle.

C.A.R.B. Exemption Reason

No impact on pollution output of vehicle.

C.A.R.B. Exempt for California Certified Vehicles Manufactured Before 1965?

Yes, but must meet tailpipe emission standards for year of vehicle.

C.A.R.B. Exempt for Federally Certified Vehicles Manufactured Before 1967?

Yes, but must meet tailpipe emission standards for year of vehicle.
