ATS Diesel 3099343176 Stage Transmission Package Ford Powerstroke - 3 E4OD 1995-1998 7.3L 4WD

The ATS Diesel Stage 3 E4OD Automatic Transmission Package is a complete performance transmission solution designed for 1995-1998 Ford Super Duty 4WD trucks with the 7.3L Power Stroke diesel engine. This comprehensive package is engineered to eliminate factory weaknesses and handle the increased torque demands of modified diesel engines.

Complete Package Includes:

• ATS Built E4OD Automatic Transmission with reinforced internals
• ATS Five Star Viskus Clutch Drive Torque Converter with billet cover and five lock-up clutches
• ATS Extra Deep Transmission Pan (adds 5 quarts of fluid capacity for improved cooling)
• ATS Billet Input Shaft made from 300M material for increased strength
• ATS Commander Torque Converter Lock-Up Controller

Key Features:

• Rated for 650-700 horsepower applications
• High performance overdrive, intermediate, and forward clutch packs with additional clutches per section
• Modified transmission pump for increased line pressure and clutch clamping force
• Modified valve body calibrated for precise shifts and increased torque capacity
• Reinforced high-stress areas with inserted bolt and thread holes
• Dyno tested under load before shipment to ensure reliability

The Commander Lock-Up Controller allows user-programmable torque converter lock-up based on vehicle speed in any forward gear, providing increased fuel economy, lower transmission operating temperatures, and more power to the ground at lower speeds. For trucks equipped with exhaust brakes, the controller synchronizes torque converter lock-up with the brake to maintain lock-up during deceleration for enhanced braking force.

The Stage 3 package is ideal for trucks used in light to heavy towing applications, modified power levels, racing, and street performance. Each transmission is backed by ATS's industry-leading 5-year/500,000-mile warranty. Please note: A separate core charge applies to this transmission package.
