Gates 85966 LOL Plus Lock-On Hydraulic Hose 3/4 Inch ID 50 Foot

The Gates 85966 LOL Plus Lock-On hydraulic hose is a versatile low-pressure hydraulic hose designed for a wide range of fluid transfer applications. This 50-foot hose features a 3/4-inch inside diameter (12 dash size) and 1.06-inch outside diameter, constructed with a durable nitrile tube and modified nitrile cover for excellent resistance to oil, weather, and abrasion.

Key Features:

• 3/4-inch (0.75") inside diameter with 1.06-inch outside diameter
• 300 PSI maximum working pressure for reliable performance
• Braided synthetic high-tensile textile cord reinforcement
• Temperature range: -40°F to 212°F
• 50-foot length (also available in different increments)
• Black nitrile cover for durability and flexibility

Applications: Recommended for petroleum-based hydraulic oils, water, glycol anti-freeze solutions, engine lubricating oils, and air applications. Compatible with Gates Field Attachable LOC Couplings (G36 Series), GLX Couplings (G44 Series), and G37/G38 barbed fittings with clamps.

Important: Lock-On hose and couplings are not recommended for pressure surge applications, critical installations such as permanent piping in residential or commercial buildings, or use with gasoline or diesel fuels unless specifically approved by Gates.
