Gates 85964 LOL Plus Lock-On Hydraulic Hose Foot - 50

The Gates 85964 LOL Plus Lock-On Hose is a versatile 50-foot low-pressure hydraulic hose designed for a wide range of fluid transfer applications. This 1/2-inch inside diameter hose features a durable synthetic rubber construction with a nitrile tube and polychloroprene cover, making it ideal for petroleum-based hydraulic oils, water, glycol anti-freeze solutions, engine lubricating oils, and compressed air.

Key Specifications:

• Inside Diameter: 1/2 inch
• Outside Diameter: 0.77 inch (19.6 mm)
• Length: 50 feet
• Working Pressure: 300 PSI
• Burst Pressure: 1200 PSI (82.7 bar)
• Temperature Range: -40°F to +212°F (-40°C to +100°C); Air applications: up to +160°F (+71°C)
• Black polychloroprene cover meets MSHA 2G flame resistance designation

Features and Benefits:

• Synthetic rubber construction provides excellent flexibility and durability
• Compatible with Gates Field Attachable LOC Couplings (G36 Series), GLX Couplings (G44 Series), and G37/G38 fittings
• Available in multiple colors for easy color-coding identification
• Nitrile tube offers superior resistance to petroleum-based fluids
• Recommended for general-purpose hydraulic applications

Important Application Notes:

Lock-On hose and couplings are not recommended for pressure surge applications or critical installations such as permanent piping in residential or commercial buildings. Do not use for gasoline or diesel fuels unless specifically approved by Gates H/C Product Application. This hose must be used exclusively with Gates couplings and fittings for proper performance and safety.
