Ksport CBM021-GR Rally Spec GR Gravel Rally Coilover Kit Adjustable Monotube - 36-Way

The Ksport Rally Spec GR (CBM021-GR) is a purpose-built gravel rally coilover system engineered to survive the brutal demands of competitive rally racing. Featuring an extended shock stroke paired with longer springs ranging from 250mm to 270mm, this kit is designed to absorb the punishment of loose surfaces, deep ruts, and high-speed compression hits that would destroy a standard street coilover.

Key Features:

• 36-way damping adjustment — simultaneous compression and rebound adjustment in a single knob for quick, easy tuning between stages
• Extended stroke and longer springs — lengthened cylinder and piston travel for vastly improved handling over rough, uneven terrain
• Suspension-type specific hardware — McPherson strut applications include inverted shocks with steel lower and top mounts; wishbone and multi-link applications include standard non-inverted shocks with aluminum top mounts
• Adjustable lower mount height adjustment — ride height is set at the lower mount, preserving full suspension travel — no compromise between ride height and shock stroke
• +/- 30mm ride height adjustment from OEM ride height
• Heavy-duty top plates and lower mounts for added strength and durability under competition loads
• 6061-T6 billet aluminum construction — mounts, collars, and spring perches are CNC-machined from aerospace-grade aluminum for a lightweight, corrosion-resistant build
• Zinc electroplated steel shock bodies — protects against rust and the elements; kit includes an anti-rust paste packet for additional protection on key areas
• Valving matched to installed spring rates — each set is tuned as a system for consistent, predictable handling

Monotube High-Pressure Design:

The CBM021-GR uses a monotube shock design with oil and gas fully separated within the cylinder. Compared to twin-tube designs, the monotube construction dissipates heat faster and more evenly, enables finer damping adjustments, and significantly reduces the risk of aeration and cavitation — resulting in more consistent damping performance across an entire rally stage.

Note: Camber top mounts are not available for Gravel Rally kits. These kits are built to order — please allow 2–3 weeks for production and delivery. Due to the extreme nature of gravel rally competition, no warranty is offered on this product.
