Manley 25690-16 Chrome Moly Pushrods Diameter Length Set of Engine Push Rod - 5/16 6.900 16

Manufacturer

Part Number

25690-16
Black Friday Price

$226.76

In Stock (10)

delivery box

Usually delivered within 2 days

Authorize Seller Badge
No Hassle Returns

No Hassle Returns

Live-in-stock inventory

Live-in-stock inventory

Fitment guaranteed

Fitment guaranteed

Product Details

The Manley 25690-16 is a set of 16 high-performance chrome moly pushrods engineered for precision valvetrain operation. Each pushrod measures 6.900 inches in length with a 5/16-inch diameter and features 0.080-inch thick walls with swedged ends for optimal strength and durability.

Manufactured from heat-treated 4130 chromoly steel with premium one-piece construction, these pushrods deliver exceptional rigidity while reducing deflection to ensure precise valvetrain operation at high RPM. The meticulously formed ends feature exact radii with excellent concentricity and closely controlled length tolerances, finished with black oxide coating for corrosion resistance.

Key Features:

  • Set of 16 pushrods
  • 6.900-inch length
  • 5/16-inch diameter
  • 0.080-inch wall thickness
  • Swedged ends for superior strength
  • Heat-treated 4130 chromoly steel construction
  • Black oxide finish
  • One-piece design for maximum reliability

Manley's 4130 chromoly pushrods with moderate wall thickness provide an ideal combination of strength and weight, offering excellent toughness and fatigue resistance for demanding street performance and racing applications.

Products specifications

Bottom Tip Diameter

5/16 in.

Bottom Tip Style

Ball

Exhaust Overall Length (in)

6.900 in.

For Use with Guideplates

Yes

Heat-Treated

Yes

Intake Overall Length (in)

6.900 in.

Oiling

Yes

One-Piece Pushrod

Yes

Pushrod Material

Chromoly

Pushrod Tube Diameter

5/16 in.

Quantity

Sold as a set of 16.

Tapered

No

Tip Attachment

Formed

Top Tip Diameter

5/16 in.

Top Tip Style

Ball

Wall Thickness (in)

0.080 in.

Push Rod Diameter

5/16

Engine Type

ICE

Product Type

Engine Push Rod

Push Rod Material

4130 Chrome Moly

Push Rod Quantity

16

Push Rod Type

Swedged End

Push Rod Wall Thickness

0.080

Title

Manley Pushrod, P/ROD-4130 5/16 6.900

Push Rod Length

6.900
