Manley 566460CE-8 Platinum Series Forged Piston Set Bore Dish LS - 4.185in 20cc 8-Pack

Manufacturer

Part Number

566460CE-8
Black Friday Price

$1,203.54

Estimated ship date Friday, December 04

Authorize Seller Badge
No Hassle Returns

No Hassle Returns

Live-in-stock inventory

Live-in-stock inventory

Fitment guaranteed

Fitment guaranteed

Product Details

The Manley 566460CE-8 is a Platinum Series forged piston set designed for Chevrolet LS-based engines running high-performance or power-adder applications.

Key Specifications:

  • Bore Diameter: 4.185 in.
  • Compression Distance: 1.065 in.
  • Rod Length: 6.125 in.
  • Stroke: 4.100 in.
  • Wrist Pin Diameter: .927 in.
  • Dish Volume: -20cc (E/D style)
  • Trough Depth: .175 in.
  • Recommended Piston Clearance: .0045 in. measured 1.100 in. from bottom of oil ring
  • Compatible Wrist Pin (Standard): Premium Chrome Moly P/N 42428 — 2.500 in. x .150 in. wall, .927 in. dia., 118g
  • Compatible Wrist Pin (Extreme Duty): 9310 Alloy P/N 42528 — 2.500 in. x .210 in. wall, .927 in. dia., 149g
  • Applications: LS-1, LS-2, LS-3, LS-6, LS-7, LS-9 (LSX, RHS, and World Warhawk blocks)

Platinum Series Construction Features:

  • 2618 alloy forgings — domestic high-strength material engineered for extreme temperatures and power-adder durability
  • Contour forgings — optimal strength-to-weight balance without internal milling that could interrupt grain structure
  • Proprietary multi-step top ring groove machining — ensures precise control of groove size, geometry, flatness, and finish for improved ring seal
  • Unique single-fixturing process — skirt turning and ring groove machining performed in one operation for superior ring groove-to-skirt squareness
  • Cam and barrel skirt profiles — engineered to maximize power output while minimizing cylinder wall wear
  • Round wire locks included
  • Pressure balance groove included

Manley Platinum Series pistons are a trusted choice among professional engine builders and performance tuners worldwide. The 566460CE-8 is ideally paired with Manley ring set P/N 46366-8 or stainless set P/N 46366ST-8.

Products specifications

Piston Quantity

8

Make

Chevrolet

Engine

LS

Bore Diameter

4.185

Compression Height

1.065

Engine Type

ICE

Product Type

Engine Piston Kit

Piston Volume

-20.00

Piston Series

Turbo Tuff?

Piston Sub-Series

Extreme Duty

Title

Manley Piston Set, PIST-4.185/1.115CD/20ccDISH E/D

Weight

491
