Manley 11410HTB-8 Titanium Intake Valve Set 2.100" ASCS

These ASCS-type valves feature a 2.100-inch head diameter and are designed to deliver exceptional strength while dramatically reducing valvetrain weight for improved engine response and higher RPM capabilities.

Key Specifications:

• 2.100" head diameter
• 0.3415" stem diameter
• 0.200" longer installed height than stock
• 5.14" overall length
• 0.29" tip length
• Under head angle/radius: 10° / 3/8"
• 0.08" margin
• Seat width/angle: 0.06"/45°
• Back cut width/angle: 0.08"/30°

Performance Features:

• One-piece forged titanium construction with grain flow (not head-welded)
• Higher hardness tip (HT) for extended durability
• Bead Loc groove (B suffix) for secure keeper retention
• Micro-polished, jewel-like surface finish
• Precision-machined in state-of-the-art CNC centers to exacting tolerances
• Ideal for high-RPM racing and performance applications

Manley titanium valves utilize premium titanium alloys that provide the optimal balance of mechanical properties, hardness, ductility, and fatigue strength at elevated temperatures. Each valve undergoes rigorous quality control inspection to ensure reliable performance in demanding racing environments. For off-road and racing use only.
