Manley 11310-8 Race Series Stainless Steel Intake Valve Stem - 2.000 11/32

Manufacturer

Part Number

11310-8
Sale Price

$188.69

Estimated ship date Monday, November 30

Authorize Seller Badge
No Hassle Returns

No Hassle Returns

Live-in-stock inventory

Live-in-stock inventory

Fitment guaranteed

Fitment guaranteed

Product Details

The Manley 11310-8 is a high-performance intake valve engineered for bracket racing, oval track, and demanding street applications. Constructed from premium NK-842 stainless steel with a chrome-plated stem and hardened valve tip, this race series valve delivers exceptional durability and heat resistance for high-RPM engines.

Key Specifications:

  • Valve Type: Intake
  • Head Diameter: 2.000 inches
  • Stem Diameter: .3415 inches (11/32")
  • Overall Length: 4.900 inches
  • Installed Height: Stock
  • Tip Length: .250 inches
  • Underhead Configuration: 12-degree angle x 3/8" radius (Pro Flo design)
  • Margin Thickness: .050 inches
  • Seat Width: .080 inches
  • Top of Head: 7-degree dish
  • Weight: 109 grams

Performance Features:

  • NK-842 stainless steel construction for superior strength and corrosion resistance
  • Chrome-plated stem reduces friction and wear
  • Hardened valve tip extends valvetrain component life
  • Swirl polished finish for optimal flow characteristics
  • Fully machined with undercut stem design to maximize airflow
  • Pro Flo underhead geometry enhances port velocity

Precision-manufactured to exacting tolerances, the Manley 11310-8 provides the reliability and performance advantage demanded by serious engine builders. Always verify existing valve head and stem dimensions before ordering to ensure proper fitment.

Products specifications

Approximate Weight (g)

139

Lock Groove Quantity

1-groove

Lock Groove Style

Conventional

Overall Valve Length (in)

5.105 in.

Overall Valve Length (mm)

129.7mm

Quantity

Sold as a set of 8.

Swirl Polished

Yes

Undercut Stem

No

Valve Head Diameter (in)

2.200 in.

Valve Head Diameter (mm)

55.9mm

Valve Head Style

7 degree dish

Valve Material

NK-842 stainless steel

Valve Seat Width (in)

0.080 in.

Valve Stem Diameter (in)

0.372 in.

Valve Stem Diameter (mm)

9.4mm

Valve Tip Length (in)

0.225 in.

Valve Tip Length (mm)

5.72mm

Make

Chevrolet

Head Diameter

2.200

Stem Diameter

0.3715

Valve Head Diameter

2.200

Engine Type

ICE

Product Type

Engine Intake Valve Kit

Engine

409

O/A Length

5.105

Seat Width

0.080

Tip Length

0.225

Top of Head

7 Degree Dish

Valve Stem Diameter

0.3715

Valve Type

Intake

Valve Series

Race Series

Valve Length

5.105

Engine Valve Quantity

8

Margin Width

0.065

Underhead Angle

12.00

Underhead Radius

3/8

Valve Head Shape

7 Degree Dish

Valve Quantity

8

Valve Sub-Series

Race Master

Valve Tip Length

0.225

Title

Manley Valve - Intake, Valve-409 R/M 2.200
