JE Pistons GM1031-059 Pro Seal MLS Head Gasket GM LSX Bore Right - 4.150 0.059

Manufacturer

Part Number

GM1031-059
Black Friday Price

$294.98

Estimated ship date Thursday, November 19

Authorize Seller Badge
No Hassle Returns

No Hassle Returns

Live-in-stock inventory

Live-in-stock inventory

Fitment guaranteed

Fitment guaranteed

Product Details

The JE Pistons Pro Seal GM1031-059 is a premium multi-layer steel (MLS) head gasket designed specifically for high-performance GM LSX engine applications. Engineered for 4.150-inch bore configurations with a 0.059-inch compressed thickness, this right-hand gasket delivers superior sealing capabilities for racing and high-boost applications where cylinder pressures can exceed 2,000 psi.

Advanced Construction Features:

  • Multi-layer stainless steel construction using AISI 304 stainless steel for exceptional strength and durability
  • Gas Stopper layer with active fold technology creates a high-pressure seal around cylinder bores similar to an o-ring without requiring machining
  • Proprietary coating system with fluoroelastomer (FKM) layers provides 100% metal encapsulation for extreme temperature and chemical resistance
  • Precision laser-cut layers with multi-stage embossing optimized for each bore size
  • Heat-treated and tempered construction reduces stress points and increases flexibility

Technical Specifications:

  • Bore diameter: 4.150 inches
  • Compressed thickness: 0.059 inches (1.50mm)
  • Series: Cooper gasket design
  • Position: Right-hand cylinder bank
  • Application: GM LSX 376 engines (2006 and later)
  • Cross-reference: SCE Gaskets CR191559R

JE Pro Seal gaskets utilize state-of-the-art embossing processes that optimize radius formation in critical bend areas, reducing stress points while improving conformability and surface contact. The proprietary coating prevents gasket adhesion to deck surfaces and eliminates the need for additional deck resurfacing. Designed for professional engine builders and serious racers, this gasket maintains its seal even under prolonged high cylinder pressure and extreme temperature cycling. Sold individually.

Products specifications

Make

Chevrolet

Prop 65

WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov

Thickness

1.50

Engine

CHEVROLET LS GEN III/IV

Industry

Automotive

Out of Stock Message

Call for Availability

Product Market

Domestic

Engine Type

ICE

Material

Composite Gasket

Title

Cylinder Head Gasket, Chevrolet, LS Gen III/IV

Cylinder Bore Diameter

105.40

Category Hierarchy

Cylinder Head Gasket

Bore Diameter Range Min Max

104.78 - 104.90

Gasket Series

Stainless Steel Cut Ring
