JE Pistons MI1003-051 Pro Seal MLS Head Gasket Mitsubishi EVO Bore - 4G63 4-8 88.3mm

Manufacturer

Part Number

MI1003-051
Black Friday Price

$190.43

Estimated ship date Thursday, November 19

Authorize Seller Badge
No Hassle Returns

No Hassle Returns

Live-in-stock inventory

Live-in-stock inventory

Fitment guaranteed

Fitment guaranteed

Product Details

The JE Pistons Pro Seal MI1003-051 is a premium Multi-Layer Steel (MLS) head gasket engineered for high-performance and racing applications on the Mitsubishi 4G63 turbocharged engine. Featuring an 88.3mm bore and 0.051" (1.3mm) compressed thickness, this gasket is purpose-built to hold up under the extreme cylinder pressures generated by boosted and built 4G63 EVO 4-8 powerplants.

Key Features:

  • Constructed from three layers of 304 stainless steel for exceptional strength and durability
  • Layers are laser-cut from raw sheet stock, then processed through a multi-step embossing operation that forms smooth, low-stress embossments for maximum sealing integrity
  • Each layer is heat treated and tempered after embossing, giving the gasket a "memory" so it maintains sealing pressure even through repeated heat cycles
  • Proprietary Viton outer layer coating seals minor surface imperfections on the block and head decks, preventing coolant and oil leakage without sticking to machined surfaces
  • CAD-designed fire-ring placement is unique to each bore size, ensuring optimal embossment distance from the cylinder bore edge
  • Available in multiple bore sizes and thicknesses to accommodate overbore builds and compression tuning
  • Suitable for naturally aspirated, turbocharged, supercharged, and high-boost street and race applications

Unlike conventional composite gaskets that rely on a separate fire ring element, the JE Pro Seal MLS design integrates the sealing function across all steel layers simultaneously. The result is superior resistance to head lift, detonation events, and thermal cycling — critical performance advantages for the high-output 4G63 platform. MPN: MI1003-051.

Products specifications

Make

Mitsubishi

Prop 65

WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov

Engine

4G63 2001-2007 EVOLUTION VII-IX / 22MM PIN

Industry

Automotive

Out of Stock Message

Call for Availability

Product Market

Sport Compact

Engine Type

ICE

Material

Multi Layer Stainless Steel

Thickness

1.30

Title

Cylinder Head Gasket, Mitsubishi, 4G63 EVO VII-IX

Category Hierarchy

Cylinder Head Gasket

Gasket Series

MLS

Cylinder Bore Diameter

88.30

Bore Diameter Range Min Max

85.00 - 87.80
