ARB CS057R Old Man Emu 2 Inch Lift Rear Leaf Spring for Toyota Land Cruiser 76 Series

The ARB CS057R is an Old Man Emu Dakar series rear leaf spring engineered specifically for the Toyota Land Cruiser 76 Series wagon. This medium-duty leaf spring provides a 2-inch lift and is designed to deliver superior performance across all terrain conditions, from harsh Outback roads to daily driving and towing applications.

Key Features:

• 2-inch lift height for improved ground clearance
• Medium-duty load rating for balanced performance
• 4+2 leaf configuration with two-stage leaf pack for optimal comfort
• Draw-tapered and diamond-cut leaves distribute load progressively over a larger surface area
• Shot-peened tension side on all leaves to reduce spring stress and extend service life
• Military wrap design provides added safety and durability
• Fully scragged to reduce the risk of sagging over time
• Re-greasable nylon interleaf anti-friction pads reduce friction at leaf tips
• Bolted leaf clamps allow installation of anti-squeak nylon liners
• Flat axle seat area ensures positive, safe axle mounting and reduces spring stress
• Load tested to ensure spring meets required specifications
• 40mm eye diameter (front and rear)

Part of ARB's integrated 4X4 suspension systems, this Old Man Emu leaf spring is the result of extensive testing and development in the demanding Australian Outback. When paired with Old Man Emu shock absorbers, this spring delivers vastly improved ride quality, handling, and load-carrying capability. The two-stage design allows the vehicle to ride primarily on the primary stage when unladen, with the secondary stage engaging to provide additional support under heavy loads. Sold individually.
