Manley 12811-8 Severe Duty Intake Valve 2.300" Head Big Block Chevy

Manufacturer

Part Number

12811-8
Black Friday Price

$301.07

1 left at this price

delivery box

Usually delivered within 2 days

Authorize Seller Badge
No Hassle Returns

No Hassle Returns

Live-in-stock inventory

Live-in-stock inventory

Fitment guaranteed

Fitment guaranteed

Product Details

The Manley 12811-8 Severe Duty intake valve set delivers race-proven strength and reliability for high-performance Big Block Chevy engines. Engineered specifically for extreme gasoline engine temperatures, these valves are manufactured from exclusive NK-842 stainless steel material that offers superior tensile strength compared to competitive alloys.

Key Specifications:

  • Head Diameter: 2.300 inches
  • Stem Diameter: 3/8 inch (0.3715 inch)
  • Overall Length: 5.244 inches
  • Tip Length: 0.250 inch
  • Underhead Angle/Radius: 12° x 3/8 inch
  • Margin: 0.050 inch
  • Seat Width: 0.080 inch
  • Top of Head: 7° Dish
  • Material: NK-842 Stainless Steel

Premium Features:

  • Chrome stems and hard tips for enhanced durability and wear resistance
  • Swirl polished underhead areas for optimized airflow
  • Fully machined combustion faces for improved combustion efficiency
  • Designed for stock installed height applications

Manley's Severe Duty valves have been fatigue tested at 40,000 psi and 1400°F, enduring up to 100 million cycles while competitive valves failed after just 100,000 cycles. The NK-844 intake valve material provides over four times the ultimate tensile strength of competing intake valve materials, making these valves the industry standard for performance and endurance in demanding racing and high-performance street applications.

Important Installation Note: Bead Loc valve locks are required for proper installation.

Products specifications

Valve Material

Stainless steel

Make

Chevrolet

Valve Stem Diameter

0.3110

Engine Type

ICE

Engine

Big Block

Product Type

Engine Exhaust Valve Kit

Head Diameter

1.900

O/A Length

5.522

Seat Width

0.100

Tip Length

0.250

Title

Manley Valve - Exhaust, Valve-S/D 1.900,+.100

Top of Head

7 Degree Dish

Valve Type

Exhaust

Valve Head Diameter

1.900

Valve Series

Severe Duty? Series

Valve Length

5.522

Engine Valve Quantity

8

Margin Width

0.075

Underhead Angle

10.00

Underhead Radius

3/8

Valve Head Shape

7 Degree Dish

Valve Quantity

8

Valve Tip Length

0.250

Stem Diameter

0.3110
