Take your 2011-2016 Ford F250/F350 Super Duty to new heights with the Zone Offroad F25 4-inch radius arm suspension lift kit. This comprehensive system is specifically engineered for 4WD diesel applications and provides the perfect combination of lift, strength, and ride quality for both daily driving and off-road performance.
Heavy-Duty Radius Arm Design:
The F25 features robust replacement radius arms constructed from fully-boxed 1/4-inch steel that are considerably stronger than factory components. These HD radius arms utilize large 2-1/2 inch greasable urethane bushings for long-term durability and bolt directly into stock locations while properly positioning the axle for correct caster alignment and wheel location. The lower mount point features Zone's popular cam lock design, making the system adjustable for 4 or 6 inches of lift.
Complete Lift System Components:
- Engine-specific full-length replacement coil springs engineered for optimal ride quality and long-term performance without sagging
- Heavy-duty 1-1/2 inch solid steel track bar with oversized high-durometer urethane bushings to properly center the front axle and limit lateral movement
- Rear 5-inch lift block kit that replaces the factory block instead of stacking blocks for safer installation
- Yellow zinc-plated front and rear U-bolts with high nuts and hardened washers
- Custom-valved hydraulic shocks or optional upgrade to Nitro series shocks for enhanced towing and handling
- Steering correction components to maintain proper geometry
Performance & Clearance:
This suspension lift provides clearance for up to 35-inch tires and delivers improved ground clearance, off-road capability, and an aggressive stance. The system is designed to maintain factory ride quality while significantly enhancing your truck's appearance and capability.
Installation & Warranty:
The F25 is one of the easiest installations on the market thanks to the use of a front track bar and rear block kit design. Different rear block options are available depending on whether your truck is equipped with factory overload springs. Backed by Zone Offroad's limited lifetime warranty and Factory Protection Plus coverage.
Note: Some trucks may require a carrier bearing drop kit for two-piece rear drive shafts to reduce post-lift driveline angles. Not designed for dually models without modification.
