The SSR GTX01 is a high-performance flow-formed wheel that combines exceptional lightweight construction with race-proven strength. This 18x10.5 wheel features a 5x114.3 bolt pattern, 22mm offset, and 73mm center bore in a sophisticated Dark Silver finish, making it an ideal choice for enthusiasts seeking aggressive fitment and cutting-edge performance.
Advanced Flow Forming Technology:
The GTX01 utilizes SSR's FFT-R (Flow Forming Technology - Race) process, creating a sturdy wheel using less material while retaining the high strength properties that SSR wheels are renowned for. The dimple engraved at the base of the spokes is lightweight technology adopted from racing wheels, with weight control technology applied after thorough strength analysis that doesn't compromise structural integrity.
Key Features:
- 10-spoke design for modern and distinguished appearance
- Direct design from GT500 racing wheels with overwhelmingly high rigidity achieved through 10 spokes that excel in structural balance
- Aggressive 18x10.5 size with 22mm offset delivers improved traction and enhanced cornering stability
- 73mm center bore for proper hub-centric fitment
- TPMS compatible for easy installation on vehicles with tire pressure monitoring systems
- Face Type C (maximum concave) design for deep dish appearance
Construction & Performance:
The center part features SSR's symbolic dimple which shaves weight and adds aggression to the wheel's appearance. The spokes are shaped to increase or decrease side thickness for each V-shape, achieving both lightness and stiffness. The flow forming process creates a wheel that's ideal for both track and street use, offering reduced unsprung weight for improved acceleration, braking response, and handling dynamics.
Finish:
The Dark Silver finish provides a sleek and timeless look while resisting fading, scratches, and corrosion for long-lasting durability and style.
Specifications:
- Diameter: 18 inches
- Width: 10.5 inches
- Bolt Pattern: 5x114.3mm
- Offset: +22mm
- Center Bore: 73mm
- Finish: Dark Silver
- Construction: Flow-Formed Aluminum Alloy
- Face Type: C (Maximum Concave)
Wheel is sold individually. Center caps available separately. Made in Japan with SSR's precision engineering and quality control standards.
