AutoMeter Marine White Trim Level Gauge

The AutoMeter 200767 is a precision electric trim level gauge designed to help boat operators monitor and optimize their boat's attitude in the water. By tracking the position of your outdrive or propeller unit, this gauge enables you to adjust trim angle for improved speed, fuel economy, comfort, and control across varying conditions and loads.

How Trim Control Works

As the outdrive is trimmed up, the propeller exerts more downward force, lifting the bow out of the water. When trimmed down, the force aligns more with the hull, keeping the bow lower. This gauge connects to a resistance-based sender in the outdrive pivot (similar to a fuel tank sender), measuring resistance from 0 ohms (fully down) to 90 ohms (fully up) to provide accurate positioning feedback.

Marine-Specific Design Features

  • Front Sealed Bezel: Enhanced water resistance protects against marine environments
  • UV Protected Pointer: Fluorescent red pointer with UV-resistant paint prevents sun damage
  • White Super Bezel: Clean, crisp appearance matches marine instrument panels
  • Air-Core Electric Movement: Quick, accurate readings without hazardous fluids inside the boat

Specifications

  • Gauge Size: 2-5/8 inches (cup/hole size: 2-5/8", outer bezel diameter: 2-7/8")
  • Sender Compatibility: 0 Ohm Down / 90 Ohm Up trim level sending unit
  • Voltage: 12 and 16 volt compatible
  • Lighting: Traditional incandescent white lighting around dial perimeter
  • Lens: Flat, clear lens
  • Dial Color: Marine white with fluorescent red pointer

What's Included

  • Trim level gauge with air-core electric movement
  • Bulb and socket assembly
  • Red and green bulb covers
  • Corrosion-resistant marine-grade mounting hardware
  • Detailed installation instructions

Warranty

Backed by AutoMeter's 12-month limited warranty, ensuring reliable performance season after season.
