COMP Cams 7245-16 Race Endurance 1.657" Od Conical Springs; 2.000" Installed Height; 16 Springs

Manufacturer

Part Number

7245-16
Black Friday Price

$675.98

1 left at this price

delivery box

Usually delivered within 2 days

Authorize Seller Badge
No Hassle Returns

No Hassle Returns

Live-in-stock inventory

Live-in-stock inventory

Fitment guaranteed

Fitment guaranteed

Product Details

The COMP Cams 7245-16 Race Endurance Conical Valve Springs are engineered for high-performance racing applications where reliability and valvetrain stability are critical. These premium valve springs feature a conical design that reduces spring mass and allows for higher RPM operation while minimizing valve float and bounce.

Key Specifications:

  • Outside Diameter: 1.657 inches
  • Installed Height: 2.000 inches
  • Conical spring design for reduced weight and improved harmonics
  • Race Endurance series construction for extended durability
  • Set includes 16 springs for V8 applications

The conical taper design of these valve springs provides progressive spring rates and helps eliminate coil bind issues common in high-lift camshaft applications. The Race Endurance series features heat-treated chrome silicon alloy construction with a precision-wound design to ensure consistent pressure and performance across the entire RPM range. These springs are ideal for racing engines, high-performance street builds, and applications requiring maximum valvetrain control at elevated engine speeds.

Note: Verify spring specifications including seat pressure, open pressure, and coil bind height match your specific camshaft and cylinder head requirements. Proper installation with correct installed height is essential for optimal performance and engine longevity.

Products specifications

Number of Springs

2

Inner Spring Inside Diameter

0.646/0.861

Coil Bind Height

1.115

Outer Bottom Spring Inside Diameter

1.225

Seat Pressure

150

Seat Height

2.05

Compatible Shims

4756

Spring Rate

600

Compatible Retainer

716-16

Damper

No

Outer Top Spring Inside Diameter

1.01

Outer Top Spring Outside Diameter

1.442

Outer Bottom Spring Outside Diameter

1.657

Compatible .570" Guide Diameter Spring Seats

4669-16

AMAZON ASIN

B00N6LTDAI

Valve Spring Series

Race Endurance

Prop 65

WARNING: Cancer and Reproductive Harm P65Warnings.ca.gov

C.A.R.B. Exempt for Foreign Vehicles Manufactured Before 1967?

Yes, but must meet tailpipe emission standards for year of vehicle.

C.A.R.B. Exempt for On-Road Vehicles?

Yes

C.A.R.B. Exempt for Racing and Off-Road Only Vehicles?

Yes, but must be a race/competition only vehicle.

C.A.R.B. Exemption Reason

No impact on pollution output of vehicle.

C.A.R.B. Exempt for California Certified Vehicles Manufactured Before 1965?

Yes, but must meet tailpipe emission standards for year of vehicle.

C.A.R.B. Exempt for Federally Certified Vehicles Manufactured Before 1967?

Yes, but must meet tailpipe emission standards for year of vehicle.

Title

Race Endurance 1.657" OD Conical Springs; 2.000" Installed Height; 16 Springs
