ICON Vehicle Dynamics K53143T Toyota Hilux Lift Stage Suspension System with Tubular UCA - 2012-2015 0-3 3

(2005-2008, 2010-2015 Toyota Hilux; 2012-2017 Toyota Camry; 1988-1996 Pontiac Grand Prix)

Manufacturer

Part Number

K53143T
Black Friday Price

$2,687.39

$3,161.63 Save 15%

In Stock (10+)

delivery box

Usually delivered within 2 days

free shipping

FREE SHIPPING

Authorize Seller Badge
No Hassle Returns

No Hassle Returns

Live-in-stock inventory

Live-in-stock inventory

Fitment guaranteed

Fitment guaranteed

Product Details

The ICON Vehicle Dynamics K53143T Stage 3 Suspension System is engineered specifically for the 2012–2015 Toyota Hilux, delivering a significant upgrade in both on-road comfort and off-road capability. Designed with the serious driver in mind, this complete system accounts for the Hilux's stiffer chassis and the wide variety of conditions in which this truck is used worldwide — requiring a more robust shock tune for consistent damping across varying terrains and payload levels.

At the heart of the front suspension are ICON 2.5" Internal Reservoir Coilover Shocks paired with ICON-engineered Eibach coil springs. The internal reservoir provides exceptional heat dissipation for extended, consistent damping performance. Height is fully adjustable from 0" to 3" of lift, enabling use of larger, more aggressive wheel and tire combinations. The corrosion-resistant CAD-plated coilover shock body features a heavy-duty 7/8" shock shaft for added strength and durability.

The rear of the system is equipped with ICON 2.0 Aluminum Series Remote Reservoir Shocks, which balance front-to-rear performance by maintaining lower operating temperatures during extended off-road use — ensuring optimal damping consistency over long durations. A rear shackle lift is employed when the front is set to the full 3" lift height, retaining the factory payload rating while maximizing suspension up-travel.

Completing the Stage 3 kit are ICON Tubular Uniball Upper Control Arms (UCA). These heavy-duty arms increase strength and durability over the factory control arms while expanding wheel travel and maintaining factory alignment specification range. They also improve caster over stock for better handling geometry.

Key Features:

  • Adjustable front ride height from 0" to 3" of lift via coilover collar adjustment
  • ICON 2.5" internal reservoir coilover shocks with ICON-engineered Eibach coil springs
  • ICON 2.0 Aluminum Series remote reservoir rear shocks for balanced front-to-rear performance
  • Corrosion-resistant CAD-plated coilover shock body with heavy-duty 7/8" shock shaft
  • Tubular uniball upper control arms — increased strength, durability, and caster improvement
  • FK rod end bearings for extended longevity and minimal deflection
  • Rear shackle lift retains factory payload rating at maximum front lift height
  • Vehicle-specific shock tune designed for the Hilux's stiffer chassis and varied payloads
  • Increased wheel travel and ride quality with no reduction in towing capacity

WARNING: This product contains chemicals known to the State of California to cause cancer, birth defects, or other reproductive harm (Proposition 65).

Products specifications

Fits

2005-2008, 2010-2015 Toyota Hilux; 2012-2017 Toyota Camry; 1988-1996 Pontiac Grand Prix

Bushings Included

No

Mounting Hardware Included

Yes

Grade Type

Performance

Coils Quantity Front

2

Add-On Part

198000 - 2 PIN COILOVER SPANNER WRENCH KIT

Maximum Lift

3

Leaf Spring Bracket Color

Black

Shocks Included

Yes

Prop 65

WARNING: This product contains chemicals known to the State of California to cause cancer, and birth defects or other reproductive harm.

Spring Color

Black

Leaf Spring Bracket Mount Hole Quantity

1

Spring Rate

650

Spring Material

Steel

Leaf Spring Bracket Material

Steel

OEM Wheels & Tires Fitment

Yes

Recommended Aftermarket Tires

33" x 11.25" (Larger tires may fit but fender trimming and modifications will be required.)

Recommended Aftermarket Wheels

ICON Alloys | 17x8.5" w/ 4.75” Backspace / 0mm Offset

Recommended Aftermarket Wheels

ICON Alloys | 20x9" w/ 5” Backspace / 0mm Offset

Recommended Aftermarket Wheels

ICON Alloys | 18x9" w/ 5” Backspace / 0mm Offset

Add-On Part

198001 - BILLET SPANNER WRENCH KIT
