Wilwood 260-13620 Compact Combination Brake Master Cylinder Kit 13/16" Bore

Wilwood's Compact Combination Master Cylinder Kit (260-13620) is engineered for limited-space brake system applications that demand the output capacity of a full-size master cylinder. This innovative design features an ultra-short 3.37" compact body that provides 2.16" of additional clearance between the mounting flange and fluid outlet compared to standard cylinders.

Key Features:

• 13/16" bore size delivers optimal brake fluid volume and pressure
• 3/8-24 banjo outlet positioned at the top radius of the cylinder bore to reduce trapped air
• Full 1.12" piston stroke meets or exceeds the stroke capacity of most full-size cylinders
• Enhanced fluid inlet port accommodates the included standard reservoir
• 11/16-20 internal threads at inlet allow custom reservoir configurations
• Black E-coated aluminum body resists corrosion and provides long-lasting durability
• Complete kit includes reservoir and mounting hardware

This master cylinder is ideal for hot rods, custom builds, and race applications where firewall or clearance constraints prevent the use of traditional full-size master cylinders. The compact design doesn't sacrifice performance, making it a premium solution for demanding brake systems.
