Wilwood 260-11449 Compact Remote Master Cylinder Bore Banjo Outlet - RM6 1/2

The Wilwood 260-11449 is an RM6 series compact remote master cylinder featuring a 1/2" bore and a banjo-style fluid outlet. Sold without a reservoir, this unit is designed for custom brake and hydraulic clutch installations where a separately sourced or remotely mounted reservoir is preferred. The lightweight, high-pressure die-cast aluminum body is finished in a durable black E-coat that resists corrosion for long service life.

Key Features:

• Bore Size: 1/2" (0.500")
• Outlet Type: Banjo fitting port — 3/8"-24 thread
• Stroke: 1.25" piston stroke
• Reservoir: Not included — compatible with Wilwood remote reservoir kits
• Mounting: Flange-mount with 2.25" on-center bolt spacing
• Body Material: High-pressure die-cast aluminum with black E-coat finish
• Style: Compact Girling/RM6 design — fully rebuildable

The RM6's compact form factor — measuring just over 4" from mounting flange to the front of the cylinder — makes it well suited for tight-space applications in racing, track, club sport, and specialty vehicle builds. The top-positioned banjo outlet minimizes the risk of trapped air in the brake line. Compatible with Wilwood reservoir kits including part numbers 260-7577 (4.0 oz.) and 260-8742 (10.0 oz.) for remote fluid supply arrangements.
