McLeod 6305504M RXT Street Twin Disc Clutch Kit Aluminum Flywheel LS 6-Bolt 9-11/16 x 1-1/8 x 10 Bronze Facing 0 Balance 168T

(Chevrolet Silverado 1500 1999-2006, Silverado 1500 HD 2002, Silverado 2500 HD 2001-06, Colorado 2009-12, K2500 1999-2000, C3500 1999-2000 + 20 more models)

Manufacturer

Part Number

6305504M
Black Friday Price

$1,436.62

2 left at this price

delivery box

Usually delivered within 2 days

free shipping

FREE SHIPPING

Authorize Seller Badge
No Hassle Returns

No Hassle Returns

Live-in-stock inventory

Live-in-stock inventory

Fitment guaranteed

Fitment guaranteed

Product Details

The McLeod RXT Street Twin Disc Clutch Kit (6305504M) is engineered for the serious street/strip performance enthusiast who demands both maximum power handling and everyday driveability. Rated to handle up to 1,000 horsepower, this complete unit pairs a billet aluminum flywheel with a twin disc clutch assembly designed specifically for LS-X engines with 6-bolt cranks.

This kit is a complete, dedicated flywheel and clutch package — no need to source a flywheel and clutch separately. McLeod Racing combines both components under a single part number for a true plug-and-play installation. The unit features a 168-tooth ring gear, 0-balance specification, and a 9-11/16" diameter x 1-1/8" x 10-spline input shaft fitment with bronze-faced clutch discs for smooth, progressive engagement.

Key Features:

  • Rated for up to 1,000 horsepower — ideal for high-performance street and strip applications
  • Twin disc design with bronze-faced clutch discs for smooth engagement and reduced pedal effort
  • Billet aluminum flywheel — lightweight construction suited for performance and track use
  • Designed for LS-X 6-bolt crank applications
  • Complete kit — dedicated flywheel and twin disc clutch in one part number
  • 168-tooth ring gear with 0-balance specification
  • Disc size: 9-11/16" diameter | Spline: 1-1/8" x 10
  • Drive to the track, make passes, and drive home — the RXT is built for both worlds

McLeod Racing's RXT Street Twin series is available in multiple configurations, including an adapter ring version (bolts to your existing flywheel) and this complete dedicated flywheel unit. The 6305504M is the complete billet aluminum flywheel version, offering the best combination of reduced rotating mass and high-horsepower clutch clamping force for LS-powered builds.

Products specifications

Fits

Chevrolet Silverado 1500 1999-2006, Silverado 1500 HD 2002, Silverado 2500 HD 2001-06, Colorado 2009-12, K2500 1999-2000, C3500 1999-2000, Silverado 2500 1999-2004, Silverado 3500 2001-06, C2500 1999-2000, K3500 1999-2000 + 16 more models

Flywheel Material

Aluminum

Balance

0 Balance - For Externally Balanced Also Order Weight Kit #####

Disc Diameter

9-11/16"

Engine

1997-2013 LS1/LS2/LS3/LS6/LS7 6 BOLT Crank

Engine Balance

Internal Balance

Ring Gear

168 tooth

Clutch Patterns

RST/RXT Steel Adapter Plate Pattern

Horsepower Rating

1000

Hub Style

Solid

magento _type

simple

Magento category

Clutch Kits

magento status

1

magento tax_class_id

2

magento visibility

3

magento_atrribute_set

Clutch Kits

magento_product_web

base

magento_store

default

Make

Chevrolet

Number of Discs

Double

Spline

1 1/8" x 10

Flywheel Included

Yes

Make

Chevrolet, GMC

Disc Material

CERAMIC

Engine

1999-2012 LS1/LS2/LS3/LS6/LS7 6 BOLT Crank

Disc Diameter

9-11/16In.

Pressure Plate Style

Diaphragm

Spline

1 1/8In. x 10

Quantity

Sold as a kit.

Input Spline Quantity

10

Pilot Bushing Included

No

Throwout Bearing Included

No

Hardware Included

Yes

Disc Style

Segmented

Alignment Tool Included

Yes

Flywheel Material

Billet aluminum

Ring Gear Tooth Quantity

168-tooth

Engine Balance

Internal

Clutch Usage

Performance
