HKS 27006-AN014 R35 GR6 Transmission Plate T1.3 Set

The HKS 27006-AN014 Plate T1.3 Set is a precision-engineered transmission component developed by HKS as part of their acclaimed R35 GT-R GR6 dual-clutch transmission upgrade program. Designed and validated through extensive high-output testing under severe circuit conditions using the HKS GT1000 specification build with slick tires, this plate set delivers the structural integrity required to support extreme power levels.

Clutch Pack Engineering:

• Fully optimized case and component layout allows an increased plate count from 6 (stock) to 8 without reducing disk or plate thickness
• New design prevents heat-induced disk distortion while delivering 110% greater pressing force than stock via a larger piston diameter — no oil pressure modifications required
• Redesigned inner oil seal offers 170% stronger pressure resistance compared to the OEM seal
• Upgraded thrust needle bearing replaced with a ball bearing for superior high-RPM support, rated to 8,500 RPM
• Overall clutch pack torque capacity is 175% greater than stock, with structural strength rated at 300% of OEM (per HKS test data)
• Bolt-on, pre-assembled and tested design supports over 1,000PS while maintaining smooth, street-drivable clutch feel

Transmission Plate Construction:

• Optimized plate layout increases cog width for superior strength compared to competing solutions
• High-strength steel construction replaces OEM aluminum plates, providing 3x the rigidity to prevent distortion and cog breakage under high-output loads
• Sandwich plate structure with a rigid center and special steel front cover improves bearing support and ensures full gear performance under race conditions

The HKS 27006-AN014 Plate T1.3 Set is a purpose-built solution for R35 GT-R builds requiring maximum drivetrain durability and torque capacity. Installation requires HKS DCT Fluid (DCTF-1 and DCTF-2) and compatible liquid gasket materials.
