Wilwood 120-9809-1-RD CPB Hydra-Mechanical Combination Parking Brake Caliper Left Hand Red

Manufacturer

Part Number

120-9809-1-RD
Sale Price

$315.52

In Stock (5)

delivery box

Usually delivered within 2 days

free shipping

FREE SHIPPING

Authorize Seller Badge
No Hassle Returns

No Hassle Returns

Live-in-stock inventory

Live-in-stock inventory

Fitment guaranteed

Fitment guaranteed

Product Details

The Wilwood 120-9809-1-RD is a Combination Parking Brake (CPB) Hydra-Mechanical Caliper engineered for rear disc brake conversions and upgrades. It uses hydraulic pressure for primary braking and an integrated mechanical locking mechanism for parking brake duty — making it an ideal solution for drum-to-disc conversions and rear axle upgrades where internal shoe-style parking brake systems are not practical.

Key Features:

  • Single-piston floating design mounts to a fixed radial bracket, maintaining precise pad-to-rotor alignment during both hydraulic and cable-actuated mechanical operation
  • 34mm (1.34") piston bore with a .81" rotor width compatibility
  • Aluminum caliper body for lightweight, high-strength construction
  • Position 1 – Left Hand (driver side) fitment; Red powder coat finish
  • Radial mount design provides nearly unlimited bracket attachment options — caliper can be positioned at any height within the compatible 11.00" to 13.00" rotor diameter range, or adjusted laterally relative to the hat and rotor offset
  • Floating mount prevents pad knock-back on C-clip rear axles with measurable side play, and keeps the caliper centered over the disc as pads wear
  • Cable-actuated parking brake lock accepts a 1/2" cable housing end at the stop bracket and a 1/8" to 9/64" cable with a crimped or welded ball end
  • Compatible with OE parking brake cables on select vehicles; aftermarket and custom cable configurations are also easily accommodated
  • Brake line port: 10mm x 1.0 thread
  • Sold individually

The CPB caliper's floating mount ensures consistent alignment when the parking brake is engaged and released, eliminating common issues associated with fixed-mount mechanical parking brake designs. The radial mounting system allows axle flange brackets to be configured for a wide variety of custom and OEM-style installations, making this caliper an exceptionally versatile component for street rods, muscle cars, and performance street builds.

Products specifications

Caliper Color

Red Powder Coat

Caliper Style

1-Piston

Pad Type

D340

Piston Area

1.38

Position

Left/Right
