The MAHLE 4530GNS-15T is a 1.5mm Gas Nitrided Steel (GNS) severe duty top piston ring designed for 4.530-inch bore engines. This premium compression ring represents the latest in high-performance piston ring technology, engineered for extreme duty applications including forced induction, high-boost, and severe operating conditions.
Gas Nitrided Steel Technology:
Gas nitriding is a case-hardening process that introduces nitrogen into the steel surface, creating exceptional hardness and durability. The GNS treatment provides superior wear resistance, scuff resistance, and extended service life compared to traditional chrome-plated or cast iron rings. This makes it ideal for engines operating under high cylinder pressures, elevated temperatures, and demanding performance conditions.
Key Features:
- 4.530-inch bore diameter for precise fitment
- 1.5mm axial thickness for strength and stability
- Gas nitrided steel construction for extreme durability
- Barrel-faced profile for optimal sealing and reduced friction
- File-to-fit design allows custom end gap adjustment
- Severe duty rating for boosted and high-performance applications
- Reduces friction while maintaining superior combustion seal
- Compatible with modern cylinder bore materials
Performance Benefits:
MAHLE pioneered the use of computer simulation and development tools to engineer rings that provide measurable horsepower gains by minimizing friction losses. The ultra-flat ring flanks maximize ring-to-piston sealing, while the gas nitrided surface resists wear and scuffing even under extreme conditions. This top ring is specifically designed for engines that demand maximum reliability under severe operating conditions including supercharged, turbocharged, nitrous oxide, and high-compression naturally aspirated applications.
Application Note:
This is a single cylinder top ring set. For complete engine builds, order the appropriate quantity based on your engine configuration (typically 8 cylinders for V8 engines, 6 cylinders for inline-six or V6 engines, etc.). Professional installation and proper ring gap measurement are recommended for optimal performance and longevity.
