JE Pistons OP1000-075 Pro Seal MLS Head Gasket Opel X20XEV 2.0L Turbo 87.5mm Bore

Manufacturer

Part Number

OP1000-075
Sale Price

$190.43

Estimated ship date Monday, November 16

Authorize Seller Badge
No Hassle Returns

No Hassle Returns

Live-in-stock inventory

Live-in-stock inventory

Fitment guaranteed

Fitment guaranteed

Product Details

The JE Pistons OP1000-075 Pro Seal MLS Head Gasket is a premium multi-layer steel (MLS) cylinder head gasket designed for the Opel X20XEV 2.0L turbocharged engine. Featuring an 87.5mm bore and 0.075-inch (1.905mm) compressed thickness, this gasket is engineered to withstand the extreme pressures and temperatures generated in high-boost performance applications.

Key Features:

  • Three-Layer 304 Stainless Steel Construction: Built from AISI 304 stainless steel, each layer is individually laser-cut and formed using state-of-the-art in-line laser cutting and multi-stage embossing technologies for maximum precision and consistency.
  • Proprietary Gas Stopper Fire Ring: A folded edge on the middle steel layer forms a combustion-sealing "gas stopper" completely around the bore opening, delivering a tighter clamp load between the head and block — critical for high-boost forced-induction engines.
  • Fluoroelastomer (FKM) Coating: All layers are coated with a proprietary fluoroelastomer (FKM / Viton-style) compound that provides exceptional temperature and chemical resistance, superior conformability, oxidation resistance, and easy removal even after exposure to extreme heat cycles.
  • 100% Metal Encapsulation: JE's proprietary coating process fully encapsulates all exposed metal edges, eliminating the raw steel edges found on lesser gaskets and providing long-term corrosion protection.
  • Optimized Embossing Formation: The advanced multi-step embossing process optimizes the radius at critical bend areas, reducing stress points and improving wet-out (contact area) for a superior seal.
  • Heat-Treated and Tempered Layers: A proprietary tempering process reduces forming-induced stress, increases flexibility, and enhances deformation retention — dramatically improving long-term durability and reliability under sustained boost pressure.
  • No Additional Deck Surfacing Required: The proprietary coating technologies typically eliminate the need for additional deck machining, simplifying installation on properly prepared surfaces.

Specifications:

  • Manufacturer Part Number: OP1000-075
  • Bore Size: 87.5mm (3.445 in.)
  • Compressed Thickness: 0.075 in. (1.905mm)
  • Construction: Multi-Layer Steel (MLS)
  • Material: AISI 304 Stainless Steel with FKM coating
  • Application: Opel X20XEV 2.0L Turbo

The JE Pro Seal OP1000-075 is the go-to MLS head gasket for engine builders and performance enthusiasts demanding a reliable, high-quality seal on turbocharged Opel X20XEV builds.

Products specifications

Prop 65

WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov

Make

OPEL

Cylinder Bore Diameter

87.50

Industry

Automotive

Out of Stock Message

Call for Availability

Engine Type

ICE

Product Market

European

Material

Multi Layer Stainless Steel

Category Hierarchy

Cylinder Head Gasket

Bore Diameter Range Min Max

86.00 - 87.00

Gasket Series

MLS

Engine

X20XEV

Thickness

1.90

Title

Cylinder Head Gasket, Opel, X20XEV
