JE Pistons FD1014-039 Pro Seal MLS Head Gasket Ford Coyote 5.0L 3.755in Bore Left Side

Manufacturer

Part Number

FD1014-039
Black Friday Price

$151.86

Estimated ship date Wednesday, November 18

Authorize Seller Badge
No Hassle Returns

No Hassle Returns

Live-in-stock inventory

Live-in-stock inventory

Fitment guaranteed

Fitment guaranteed

Product Details

The JE Pistons FD1014-039 Pro Seal Multi-Layer Steel (MLS) head gasket is a race-proven sealing solution engineered for the Ford Coyote 5.0L engine. Designed for demanding high-performance and forced induction builds, this left-side gasket features a 3.755" bore and 0.039" compressed thickness. JE Pro Seal gaskets have earned their reputation on the most demanding stages in motorsports, including NASCAR, NHRA, and World of Outlaws competition.

Key Features:

  • Premium AISI 304 Stainless Steel Construction — Every layer is manufactured from high-grade 304 stainless steel using state-of-the-art in-line laser cutting and multi-stage embossing technology, ensuring precise tolerances and consistent quality.
  • Individually Cut and Formed Layers — Each layer of the multi-layer steel stack is individually cut and formed to optimize sealing performance and conformability across the entire mating surface.
  • Proprietary 4-Step Coating Process — Multiple layers of proprietary coatings, including a fluoroelastomer (FKM) layer, provide 100% encapsulation of all exposed metal edges. This delivers superior chemical resistance, oxidation protection, and improved removal after extended service — even eliminating the need for additional deck surfacing in most applications.
  • Optimized Embossing Formation — JE's advanced embossing process optimizes the radius in critical bend areas, reducing stress concentrations, improving conformability, and maximizing wet-out (contact area) for a superior seal.
  • Stress Stabilization and Tempering — A proprietary tempering process reduces forming-induced stress, lowering hardness and brittleness while increasing flexibility and deformation retention for long-term durability and reliability.

Specifications:

  • Gasket Type: Multi-Layer Steel (MLS)
  • Bore: 3.755"
  • Thickness: 0.039"
  • Side: Left
  • Application: Ford Coyote 5.0L (2011–Present)
  • Material: AISI 304 Stainless Steel

Sold individually. Two gaskets are required for a complete engine build (left and right sides sold separately). Designed to meet the demands of both street performance and all-out race applications, the JE Pro Seal FD1014-039 delivers professional-grade sealing technology for the Ford Coyote 5.0L platform.

Products specifications

Make

Ford

Prop 65

WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov

Thickness

1.00

Engine

MODULAR FORD

Industry

Automotive

Out of Stock Message

Call for Availability

Product Market

Domestic

Engine Type

ICE

Material

Multi Layer Stainless Steel

Category Hierarchy

Cylinder Head Gasket

Gasket Series

MLS

Title

Cylinder Head Gasket, Ford, Modular Ford

Cylinder Bore Diameter

95.40

Bore Diameter Range Min Max

92.20 - 94.90
