Weld Racing 71HB7090B62A RT-S S71 17x9 Black Forged Aluminum Wheel 5x4.75 6.2in Backspace High Pad

The Weld Racing RT-S S71 is a premium forged aluminum wheel engineered for serious street and strip performance. Built with a 3-piece welded construction, this 17x9-inch wheel delivers an outstanding strength-to-weight ratio by combining a forged billet center with cold forged rim shells — the same proven formula that has defined Weld Racing's legacy on the track and the street.

This specific configuration features a black anodized center, a 5x4.75-inch (5x120.65mm) bolt pattern, 6.2-inch backspace, and a +30mm offset. It is built with the High Pad mounting configuration, designed to clear modern super cars and high-performance vehicles equipped with large, fixed opposed-piston caliper systems such as factory-installed Brembo brakes and aftermarket road-racing systems from Baer, Wilwood, and others.

Key Features:

• 3-piece modular welded construction for superior strength-to-weight ratio
• Forged billet aluminum center with black anodized finish
• Cold forged rim shells for maximum durability
• High Pad mounting height — clears large multi-piston opposed-piston calipers
• Available in Low, Medium, and High Pad heights to accommodate virtually any brake package
• Tested with F.E.A. (Finite Element Analysis) and in-house destructive testing for verified safety
• Meets SAE J2530 Aftermarket Wheel (Street) Standards
• 17-inch diameter wheels require conical lug nuts (not included)
• Center cap and valve stem included
• Proudly made in Kansas City, MO USA

Specifications:

• Diameter: 17 in.
• Width: 9.0 in.
• Bolt Pattern: 5x4.75 in. (5x120.65mm)
• Backspace: 6.2 in.
• Offset: +30mm
• Pad Height: High Pad
• Finish: Black Anodized Center / Polished Shell
• Beadlock: No
• Load Rating: 1,580 lbs. per wheel
• Material: Forged Aluminum

The Weld Racing RT-S S71 is the go-to choice for performance enthusiasts who demand race-proven engineering with street-legal versatility — from classic muscle cars to today's modern performance platforms.
