MAHLE 51497CP Standard Piston Ring Set with Shallow Groove Design

(Ford F-150 1987-96, Mustang 1986-95, Explorer 1996-2001, F-250 1987-97, Bronco 1987-96, Thunderbird 1986-88, 1991-93, F-350 1993-98 + 46 more models)

Manufacturer

Part Number

51497CP
Black Friday Price

$62.41

In Stock (8)

delivery box

Usually delivered within 2 days

free shipping

FREE SHIPPING

Authorize Seller Badge
No Hassle Returns

No Hassle Returns

Live-in-stock inventory

Live-in-stock inventory

Fitment guaranteed

Fitment guaranteed

Product Details

The MAHLE 51497CP is a premium OE-quality piston ring set designed for 4.000-inch bore engines with shallow groove pistons. This complete 8-cylinder set features MAHLE's advanced engineering and proven quality that has made them the world's largest piston ring manufacturer.

Key Features:

  • Complete 8-cylinder piston ring set (sold as 8 individual cylinder sets)
  • Designed for 4.000-inch standard bore applications
  • Ring dimensions: 1.5mm top compression ring, 1.5mm second ring, 4.0mm oil ring assembly
  • Shallow groove design for specific piston configurations
  • Cast iron top compression ring with barrel face for instant break-in
  • Carbon steel second ring with positive twist for superior oil control
  • CP-20 oil ring assembly with exclusive 20-degree ear angle for optimal cylinder wall sealing
  • High tensile strength and excellent hardness with low ring mass

Performance Benefits:

  • Pre-lapped design seats immediately, virtually eliminating break-in time
  • Optimized ring materials, tension, and coatings for reduced friction and extended service life
  • Superior oil control and combustion gas management
  • Minimizes blow-by and provides excellent cylinder conformability
  • Reduces engine oil consumption while maximizing performance
  • Stress resistance and minimal groove pound-out for long service life

MAHLE Original piston rings (formerly Perfect Circle) have been trusted by professional automotive technicians for over 100 years. These rings incorporate the latest OE technology and engineering to deliver exceptional quality, durability, and performance for both modern computer-controlled engines and classic rebuilds.

Products specifications

Fits

Ford F-150 1987-96, Mustang 1986-95, Explorer 1996-2001, F-250 1987-97, Bronco 1987-96, Thunderbird 1986-88, 1991-93, F-350 1993-98, E-350 Econoline 1993-96, E-150 Econoline 1987-96, LTD 1986, E-250 Econoline 1987-91, 1993-96 + 42 more models

Bore (in)

4.000 in.

Bore (mm)

101.600mm

File Fit

No

Gapless

No

Notes

Taper face torsional design second ring. Shallow oil groove.

Oil Ring Included

Yes

Oil Ring Material

Stainless steel

Oil Ring Tension

Standard

Oil Ring Thickness

4.0mm

Quantity

Sold as a set.

Second Ring Facing Material

Cast iron

Second Ring Included

Yes

Second Ring Material

Cast iron

Second Ring Thickness

1.5mm

Top Ring Facing Material

Cast iron

Top Ring Included

Yes

Top Ring Material

Cast iron

Top Ring Thickness

1.5mm

Piston Ring Material

Cast Iron

Piston Ring Size

Standard

Piston Ring Type

Standard
