ARP AZQ8800-2B M14 x 2.0 Individual Cylinder Head Stud

The ARP AZQ8800-2B is a premium individual cylinder head stud featuring M14 x 2.0 metric threading and a 9/16 inch hex head. This replacement stud is manufactured from ARP's high-grade 8740 chrome moly alloy steel, providing exceptional strength and reliability for high-performance engine applications.

Advanced Manufacturing Process:

• Constructed from premium grade 8740 chrome moly alloy steel
• Precision heat-treated to 190,000 psi tensile strength
• Centerless ground for exceptional concentricity and straightness
• Thread rolled after heat treatment for superior fatigue resistance
• Provides significantly greater strength than OEM fasteners

ARP head studs are manufactured using a vertical heat-treatment process in special racks to ensure complete heat penetration throughout the material. Following heat treatment, each stud undergoes centerless grinding to achieve near-perfect concentricity. The threads are then rolled after heat treatment, which delivers dramatically improved fatigue strength compared to studs threaded before heat treatment. This individual stud is sold separately and can be used as a replacement for damaged studs or to customize head stud configurations for specific engine builds.

Applications: Suitable for performance engine builds, racing applications, and high-boost forced induction setups where maximum clamping force and head gasket sealing are critical.
