Wiseco Pistons K554M785 Pistons

Manufacturer

Wiseco Pistons

Picture for manufacturer Wiseco Pistons RCS07340 73.4 Mm Black Anodized Piston Ring Compressor Sleeve

Part Number

K554M785
13 reviews
04/19/2034 7:55 AM
Sale Price

$689.93

In Stock (5)

delivery box

Usually delivered within 2 days

free shipping

FREE SHIPPING

Select Your Vehicle:

Add To Cart

Check out with

PayPay

Check out with

ApplePay
Authorize Seller Badge
No Hassle Returns

No Hassle Returns

Live-in-stock inventory

Live-in-stock inventory

Fitment guaranteed

Fitment guaranteed

Product Details

Wiseco Pistons K554M785 Pistons

Wiseco Pistons K554M785 Pro Tru Pistons
Sport Compact Series
Set of 4 Pistons
Recommended RingSet: 7850XX
Rings & Pins Included

World renowned for our work building race winning pistons, Wiseco utilizes experience from a diverse background of the most sophisticated sport compact engines.

Wiseco?s Sport Compact Pro Tru line creates the best value in forged pistons today. These American made pistons are forged and machined by skilled Ohio craftsmen with state-of-the-art forging presses and CNC machines. By using dedicated forgings specific to the final piston shape, Pro Tru pistons are stronger and lighter than industry standards.

Pro Tru sets include plasma moly 1/16, 1/16, 3/16 pre-gapped ring packages which provide excellent seal, friction reduction, and long life. Pro Tru pistons also come in a variety of volumes that allow the engine builder to choose the exact compression ratio required for their engine.

Products specifications

Bore

78.5mm

Bore (in)

3.090 in.

Bore (mm)

78.500mm

Comp Height

31.95

Comp Ratio

8.5:1

Compression Distance (in)

1.258 in.

Dome Volume

-13

File Fit

No

Gapless

No

Gram Weight

275

Oil Ring Material

Stainless steel

Oil Ring Tension

Standard

Oil Ring Thickness

2.8mm

Pin Diameter (in)

0.787 in.

Piston Head Volume (cc)

+13.00cc

Piston Material

Forged aluminum

Piston Style

Dish, with four valve reliefs

Quantity

Sold as a kit.

Rod

133

Second Ring Facing Material

Phosphate coated

Second Ring Material

Cast iron

Second Ring Thickness

1.2mm

Stroke

83.5

Top Ring Facing Material

Gas nitrided

Top Ring Material

Steel

Top Ring Thickness

1.0mm

Wrist Pin Style

Press-fit or floating

A REFERENCE TO CAR MODEL AND YEAR WILL BE A GOOD REMINDER OF CORRECT PART ORDERED
