Strange Engineering B3362 Fast Fill Brake Master Cylinder with Remote Reservoir

The Strange Engineering B3362 is a high-performance fast fill brake master cylinder designed specifically for drag racing applications including dragsters and funny cars. This single master cylinder features a stepped bore design that delivers short pedal travel with less effort, making it ideal for two-wheel braking systems.

Master Cylinder Features:

• Billet aluminum body with clear anodized finish for corrosion resistance
• Dual stepped bore design: 1.122-inch primary bore moves large fluid volume, 0.777-inch secondary bore applies high pressure
• Internal pop-off valve regulates transition between bores
• Brake line banjo fitting with male -3 AN end
• -3 AN brake fluid inlet fitting
• Integral vertical mounting flange with 21/64-inch holes on 2.250-inch centers
• Single outlet configuration

Remote Reservoir Features:

• 6061-T6511 billet aluminum construction with clear anodized finish
• Heat-resistant design outperforms plastic reservoirs
• External max/min fluid level markings for easy monitoring
• Threaded cap with internal diaphragm for fluid displacement
• Male -3 AN outlet fitting included
• Can be mounted in convenient location above calipers to eliminate residual pressure valves

Important Notes: Designed for drag racing use only. -3 AN brake lines and fittings are not DOT approved for street use. Silicone brake fluid is not recommended. Always check brake pressure before operating vehicle.
