King Engine Bearings CR807HPND020 HP-Series Connecting Rod Bearing Set Chevy SBC 307/350 Gen III/IV Narrowed Dowel .020 Undersize

(Chevrolet Silverado 1500 1999-2013, Silverado 1500 HD 2001-03, 2005-06, Suburban 1500 1995-2014, Camaro 1967-2002, 2010-16, Corvette 1962-2013 + 297 more models)

Manufacturer

Part Number

CR807HPND020
Black Friday Price

$118.89

Estimated ship date Friday, December 04

Authorize Seller Badge
No Hassle Returns

No Hassle Returns

Live-in-stock inventory

Live-in-stock inventory

Fitment guaranteed

Fitment guaranteed

Product Details

The King Engine Bearings CR807HPND020 is an HP-Series connecting rod bearing set engineered for high-performance Chevrolet Small Block, 307ci, 350ci, and Gen III/IV engines. This set features King's proprietary Alecular bi-metal structure — an aluminum/tin/silicon alloy top layer bonded to a high-strength steel backing — delivering a harder bearing surface with superior embeddability and conformability compared to traditional tri-metal designs.

Key Features:

  • Alecular Bi-Metal Construction: 0.015" thick aluminum/silicon alloy top layer provides a load capacity of 8,000 psi, resisting surface migration and extrusion under high loads and short-duration stress
  • Narrowed Profile: Rod bearings are narrowed on the crank cheek side to clear large-radius aftermarket crankshafts
  • Enlarged, Chamfered Oil Holes: 5/16" chamfered oil holes promote improved oiling and lubrication at high RPM
  • Greater Eccentricity: Provides superior oil distribution at high RPM for enhanced protection
  • Increased Bearing Height: Improves bearing-to-bore contact, heat transfer, and reduces spin potential at high RPM
  • Dowel Holes Included: Dowel holes positively locate the bearing shell, critical for aluminum connecting rod applications where thermal expansion can reduce bearing crush
  • Bull's Eye Tolerance: Wall thickness controlled to ±0.0001" — significantly tighter than industry standard
  • 450°F Heat Threshold: Superior protection against friction and thermal stress
  • Corrosion Resistant: Alecular silicon material withstands alcohol and methanol fuel exposure
  • Size: .020" Undersize (for crankshafts that have been ground .020" undersize)

The HP-Series is the ideal choice for high-load, short-duration racing applications including drag racing, tractor pulling, and monster trucks, as well as street/strip and forced-induction builds using blown, turbocharged, nitrous, or alcohol-fueled combinations with aftermarket crankshafts. Also suited for medium-load circle track engines running nodular cast iron crankshafts.

Note: "Undersize" refers to a thicker bearing shell used when the crankshaft journal has been machined down. A .020" undersize bearing is paired with a crankshaft ground .020" below the original journal diameter. This set includes the "D" (Narrowed) and "N" (Dowel) designations in the part number suffix.

Products specifications

Fits

Chevrolet Silverado 1500 1999-2013, Silverado 1500 HD 2001-03, 2005-06, Suburban 1500 1995-2014, Camaro 1967-2002, 2010-16, Corvette 1962-2013, Silverado 2500 HD 2001-19, Tahoe 1968-2014, Impala 1962-96, 2006-09, Colorado 2009-12 + 293 more models

Additional Shell Thickness

+.010in

Crank Undersized

-0.020in

Size

0.20in (0.50mm)

Undersize

020

Material

alecular (racing line)

Housing Diameter

56.52 / 56.51 mm || 2.225 / 2.225 inch

STD Max Thickness

1.573

Shaft UnderSize

020

STD Shaft Diameter

53.34 / 53.31 mm || 2.100 / 2.099 inch
