COMP Cams 12-466-8 Xfi 218/224 Hydraulic Roller Camshaft for Chevrolet Small Block

(GMC G2500 1979-95, Yukon 1992-95, K1500 1979-86, 1988-95, C1500 1979-86, 1988-95, K2500 1979-86, 1988-95, Jimmy 1970-91 + 238 more models)

Manufacturer

Picture for manufacturer COMP Cams

Part Number

12-466-8
5 reviews
Sale Price

$577.95

In Stock (10+)

delivery box

Usually delivered within 2 days

Check out with

ApplePay
Authorize Seller Badge
No Hassle Returns

No Hassle Returns

Live-in-stock inventory

Live-in-stock inventory

Fitment guaranteed

Fitment guaranteed

Product Details

The COMP Cams 12-466-8 Xfi hydraulic roller camshaft is engineered to deliver exceptional performance for Chevrolet small block engines. This camshaft features a 218/224 duration split at 0.050" lift, providing an aggressive profile optimized for street/strip applications with improved throttle response and substantial horsepower gains in the 2,500-6,500 RPM range.

Camshaft Specifications:

  • Advertised Duration: 276° Intake / 282° Exhaust
  • Duration at 0.050": 218° Intake / 224° Exhaust
  • Valve Lift (with 1.5 ratio rocker): 0.525" Intake / 0.540" Exhaust
  • Lobe Separation Angle: 112°
  • Hydraulic roller design for reduced friction and increased durability
  • Core material: precision-ground billet steel

Performance Characteristics:

  • Ideal power band: 2,500-6,500 RPM
  • Moderate lope idle with strong mid-range torque
  • Requires aftermarket converter and higher compression ratio (9.5:1 minimum recommended)
  • Excellent choice for vehicles with 3.73-4.56 gear ratios
  • Compatible with stock or aftermarket fuel injection and carburetor systems

This Xfi series camshaft requires hydraulic roller lifters, pushrods, and appropriate valve springs (not included). COMP Cams recommends verifying piston-to-valve clearance during installation. Designed specifically for Chevrolet small block V8 engines including 262, 265, 267, 283, 302, 305, 307, 327, 350, and 400 cubic inch displacements.

Products specifications

Fits

GMC G2500 1979-95, Yukon 1992-95, K1500 1979-86, 1988-95, C1500 1979-86, 1988-95, K2500 1979-86, 1988-95, Jimmy 1970-91, C3500 1979-86, 1988-95, K2500 Suburban 1979-86, 1992-95, K3500 1979-86, 1988-95, C15/C1500 Pickup 1967-74 + 234 more models

Advertised Exhaust Duration

276

Exhaust Valve Lift

0.565

Intake Valve Lift

0.57

Grind Number

268XFI HR-13

Camshaft Material

Austempered Ductile Iron

Cam and Lifter Kit Upgrade

CL12-466-8

K-Kit Upgrade

K12-466-8

SK-Kit Upgrade

SK12-466-8

Camshaft Series

XFI

Usage

Street/Performance

Assembly Lubricant Included

No

Lifters Included

No

Valve Springs Required

Yes

Prop 65

WARNING: Cancer and Reproductive Harm P65Warnings.ca.gov

C.A.R.B. Exempt for Foreign Vehicles Manufactured Before 1967?

Yes, but must meet tailpipe emission standards for year of vehicle.

C.A.R.B. Exempt for On-Road Vehicles?

No

C.A.R.B. Exempt for Racing and Off-Road Only Vehicles?

Yes, but must be a race/competition only vehicle.

C.A.R.B. Exempt for California Certified Vehicles Manufactured Before 1965?

Yes, but must meet tailpipe emission standards for year of vehicle.

C.A.R.B. Exempt for Federally Certified Vehicles Manufactured Before 1967?

Yes, but must meet tailpipe emission standards for year of vehicle.

Advertised Intake Duration

268

Camshaft Gear Attachment

3-Bolt

LOBE SEPARATION

113

Lifter Type

Hydraulic Roller

Cam Type

Hydraulic Roller

AMAZON ASIN

B001G7CWDE

Basic Operating RPM Range

1,800-5,800

Exhaust Duration at .050 inch Lift

224

Intake Duration at .050 Inch Lift

218

Engine Family

Chevrolet 262-400 c.i. 8 Cylinder (1958-1998)
