The MSD 32209 Super Conductor 8.5mm Spark Plug Wire Set is a performance ignition wire set custom-fit for Ford 5.0L Mustangs. Engineered from the inside out, these wires deliver incredibly low resistance without compromising electromagnetic interference suppression — giving your ignition system everything it needs to fire efficiently and reliably.
At the heart of the Super Conductor wire is a copper alloy conductor wound extremely tight around a specially formulated center core. Each foot of finished wire contains over 40 feet of tightly wound conductor, resulting in only 40–50 ohms of resistance per 12 inches — the lowest resistance of any helically wound spark plug wire available.
The tight helical winding combined with a ferro-magnetic impregnated center core creates a highly effective Electro Magnetic Interference (EMI) choke. This choke keeps EMI contained within the wire, preventing interference with onboard electronics, sensors, and ignition components.
The outer sleeve is constructed from a proprietary blend of silicone and synthetic material over an extra-heavy glass braid and dielectric insulator. This jacket is highly resistant to high heat, abrasion, and tears — ideal for the demanding underhood environment of a performance vehicle.
The 8.5mm terminals feature dual crimp construction with snap-lock boots — one crimp secures the sleeve and a separate crimp grasps the conductor — ensuring a tight, corrosion-resistant connection at every plug and coil.
Key Features:
- 8.5mm Super Conductor spiral core wire construction
- Ultra-low resistance: only 40–50 ohms per 12 inches
- RFI suppression equivalent to a 1,500-ohm wire
- Ferro-magnetic impregnated center core for effective EMI choke
- Silicone/synthetic outer jacket — heat, abrasion, and tear resistant
- Dual crimp stainless steel terminals with snap-lock boots
- Red jacket finish
- Custom-fit for Ford 5.0L V8 applications ('94–'95)
The MSD 32209 is a direct bolt-on upgrade for the factory ignition wiring, delivering measurable improvements in spark energy delivery and EMI control for street and performance-driven Ford 5.0L builds.
