NGK 3784 PTR5D-10 Laser Platinum Spark Plug 14mm Resistor

(Chevrolet Silverado 1500 1999-2013, Silverado 1500 HD 2001-06, Suburban 1500 2000-14, Camaro 1998-2002, 2010-15, Corvette 1996-2013 + 95 more models)

Manufacturer

Part Number

3784
Black Friday Price

$9.29

$10.55 Save 12%

In Stock (10+)

delivery box

Usually delivered within 2 days

Authorize Seller Badge
No Hassle Returns

No Hassle Returns

Live-in-stock inventory

Live-in-stock inventory

Fitment guaranteed

Fitment guaranteed

Product Details

The NGK 3784 Laser Platinum spark plug (PTR5D-10) is a double platinum, resistor-type spark plug built for long service life and dependable ignition in automotive applications. It has a laser-welded platinum center electrode tip and a platinum ground electrode. Together these resist wear and help keep idle stable, resist fouling, and support efficient combustion. NGK is a leading original equipment spark plug supplier, and this plug suits vehicles that came with fine wire platinum plugs from the factory.

Key Features:

  • Laser-welded platinum on the center and ground electrodes for a slow wear rate
  • Fine wire (1.0 mm) projected platinum center electrode
  • Copper core for heat dissipation and a wide heat range
  • High-grade alumina silicate ceramic insulator for strength and heat transfer
  • Trivalent metal plating resists corrosion and seizing, which helps installation and removal
  • Corrugated insulator ribs help prevent flashover, and triple seals prevent leakage
  • Built-in resistor helps suppress radio frequency interference

Specifications:

  • NGK stock number: 3784
  • NGK plug number: PTR5D-10
  • Heat range: 5
  • Thread size: 14 mm, M14-1.25 pitch
  • Thread reach: 17.5 mm (0.689 in.)
  • Seat type: Tapered
  • Hex size: 16 mm (5/8 in.)
  • Pre-set gap: 0.040 in. (1.0 mm)
  • Resistor: Yes, approximately 5k ohm
  • Center electrode: Platinum, projected
  • Ground electrode: Platinum
  • UPC: 087295137840

Cross-references: ACDelco 41-805, 41-962; Autolite APP104, APP104DP2, APP105, APP106; Bosch 4304, 4305, 8104, 8119, HGR8DDP, HGR9DDP, HR8DPP33X, HR8LPP33U; Champion 7015-2; DENSO 4511, 4713, IT16TT, PT16TT; Motorcraft AGRF22PP1, AGSF32FEM.

This plug is a good choice for replacement or for an upgrade over standard nickel plugs, with long-lasting performance and reliable starts.

Products specifications

Fits

Chevrolet Silverado 1500 1999-2013, Silverado 1500 HD 2001-06, Suburban 1500 2000-14, Camaro 1998-2002, 2010-15, Corvette 1996-2013, Silverado 2500 HD 2001-17, Tahoe 1998-2014, Colorado 2009-12, S10 1998-2001, 2003, Impala 2006-09 + 90 more models

Stock Number

3784

Part Number

PTR5D-10

Seat Type

Tapered

Center Electrode Tip Material

Platinum

Electrical Terminal Type

Non-Removable Nut

Ground Electrode Core Material

Nickel

Manufacturer Heat Range

5

Ground Electrode Quantity

1

Insulator Height

53.00

Hex Size

5/8

Ground Configuration

Standard

Pre-Gap Size

.040

Center Electrode Core Material

Copper

Reach

.708

Ground Electrode Tip Design

Standard

Thread Diameter

14.00

Resistance

5000
