Advanced Clutch T2SS-B01 Mod-Twin 225 XT Sprung Street Clutch Kit with Flywheel

(2009-2016 BMW Z4; 2009-2015 BMW 335i; 2009-2016 BMW 535i; 2009-2010 BMW 535i xDrive; 2009-2013 BMW 135i; 2009-2015 BMW 335i xDrive + 4 more models)

Manufacturer

Part Number

T2SS-B01
Black Friday Price

$1,916.07

Estimated ship date Wednesday, December 02

Authorize Seller Badge
No Hassle Returns

No Hassle Returns

Live-in-stock inventory

Live-in-stock inventory

Fitment guaranteed

Fitment guaranteed

Product Details

The Advanced Clutch Technology (ACT) T2SS-B01 Mod-Twin 225 XT Sprung Street Clutch Kit is a high-performance twin disc clutch system engineered for high-powered AWD street applications. This modular dual disc clutch kit delivers an outstanding 850 ft/lbs of torque capacity — 177% over OEM — while maintaining a light, progressive pedal feel and smooth engagement quality. At its core, the design pairs twice the organic friction surface area with an ultra-durable sprung Mono-Drive hub, eliminating the harsh engagement and heavy pedal effort typically associated with twin disc clutches. Each diaphragm spring undergoes an exclusive four-stage heat treating process to ensure a consistent, fatigue-resistant pedal feel over the long term. Steel-backed organic friction plates provide a stable friction coefficient, excellent heat capacity, and extended clutch life, while uniformly transferring torque to the Mono-Drive sprung hub assembly to reduce driveline shock from torsional vibration and protect input shaft life. The fully modular construction makes this clutch completely rebuildable, with most components available for individual replacement. All ACT Mod-Twin clutches are 100% clamp load tested, dynamically balanced, and SFI 1.2 certified.

Key Features:

  • 850 ft/lbs torque capacity — 177% over OEM
  • 8.8 in (225 mm) diameter sprung organic disc, puck-style ceramic friction plates
  • 26-spline, 1.375 in input shaft fitment
  • Xtreme pressure plate with forged aluminum cover and exclusive four-stage heat-treated diaphragm spring
  • Sprung Mono-Drive hub assembly reduces torsional vibration and driveline shock
  • CNC-machined, dynamically balanced flywheel included
  • Patented Monoloc Collar included
  • Release bearing, alignment tool, pilot bearing, flywheel bolts, and grease included
  • Fully modular and rebuildable design — most components sold separately
  • SFI 1.2 certified; 100% clamp load tested and dynamically balanced
  • Backed by ACT's one-year performance warranty

Designed for street and street/strip use, the T2SS-B01 is ideal for turbocharged BMW inline-six applications. It fits select 2009–2016 BMW models including the 135i, 335i, 335i xDrive, 335is, 535i, 535i xDrive, 435i, 435i xDrive, M235i, and Z4 sDrive35i equipped with N54 or N55 3.0L turbocharged engines. Note: Prop 65 warning applies — see product details. Clutch slave cylinder, master cylinder, and pressure plate bolts are not included.

Products specifications

Fits

2009-2016 BMW Z4; 2009-2015 BMW 335i; 2009-2016 BMW 535i; 2009-2010 BMW 535i xDrive; 2009-2013 BMW 135i; 2009-2015 BMW 335i xDrive; 2014-2016 BMW 435i; 2011-2013 BMW 335is; 2014-2016 BMW M235i; 2014-2016 BMW 435i xDrive

SFI

1.2

Torque Capacity (ft/lbs.)

850

Prop 65

WARNING: Cancer and Reproductive Harm - www.p65warnings.ca.gov
Warning: This product can expose you to chemicals including carbon black, glass wool fibers, or silica (in clutch discs), chromium and nickel, which are known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit www.P65Warnings.ca.gov

Product Weight (lbs.)

33.1

Title

ACT Mod-Twin 225 XT Sprung Street

Torque Capacity Over OE

177%
