Firestone 9545 Air Tank 5 Gallon 7in. x 34in. (6) 1/2in. NPT Ports (1) 1/4in. NPT Port 150 PSI Black

The Firestone 9545 is a 5-gallon compressed air reservoir tank designed to work in conjunction with an on-board air compressor system, providing a ready supply of pressurized air for air spring and air suspension helper applications. By storing pre-compressed air, this tank allows for faster inflation of air springs compared to relying solely on a compressor.

Key Features:

• 5-gallon capacity — holds a substantial volume of compressed air for air spring systems
• (6) 1/2 in. NPT ports and (1) 1/4 in. NPT port — offers flexible plumbing configurations for compressors, valves, and air lines
• 150 PSI maximum working pressure — robust rating suitable for demanding suspension applications
• SAE J10 compliant — manufactured and pressure-tested to twice the working pressure per SAE J10 specifications
• Internal and external baked black enamel coating — resists corrosion for long service life in underbody and engine bay environments
• Steel tank construction with brass fittings — durable and reliable for automotive and light truck use

Specifications:

• Tank Capacity: 5 gallons
• Dimensions: 34 in. long x 7 in. diameter
• Ports: (6) 1/2 in. NPT, (1) 1/4 in. NPT
• Maximum Pressure: 150 PSI
• Finish: Baked black enamel (inside and out)
• Compliance: SAE J10
• Warranty: 2-year limited

Firestone air suspension tanks are an ideal upgrade for light trucks, SUVs, and RVs running air helper spring systems, providing the air volume needed to level loads quickly and consistently.
