The Baja Designs 44-9589 S1 Knuckle Pods Light Kit is a steerable auxiliary lighting solution that mounts a pair of S1 LED light pods directly to your Jeep's front steering knuckles using GateKeeper Off-Road patented brackets. Because the lights are fixed to the knuckles, they turn with your front wheels — illuminating exactly where your tires are pointed, not just straight ahead.
This kit comes equipped with the Trail Lens in Baja Amber, a performance-driven lens optic engineered specifically for challenging off-road conditions including dust, rain, snow, and fog. The Baja Amber lens reduces glare and enhances contrast, giving you a cleaner, more defined view of the terrain ahead. The Trail Lens expands on Baja Designs' ClearView® technology by widening both the vertical and horizontal beam spread, delivering the right amount of throw for slow-speed technical driving — rock gardens, off-camber sections, and tight trail obstacles.
S1 Light Pod Specifications (Per Light):
- Output: 2,320 raw lumens utilizing 1 high-output LED
- Wattage/Current: 20W / 1.45A
- Dimensions: 2.1" x 2.1" x 2.1"
- Weight: 0.4 lbs per light
- Safe Voltage Range: 9–28V
- LED Life Expectancy: 49,930 hours
- Lens: Hard coated polycarbonate
- Housing: Hard anodized and powder coated cast aluminum
- Bezel: Billet machined aluminum
- Hardware & Bracket Material: Stainless steel
- Waterproof Rating: IP69K (submersible up to 9 ft, pressure washable)
- Impact Rating: IK10 compliant
- Mil-Spec Tested: Exceeds MIL-STD-810G
Key Features:
- Steerable mounting — lights track with wheel direction for trail-focused illumination
- Low-profile placement clear of lift kits and aftermarket bumpers
- GateKeeper Off-Road patented steering knuckle brackets
- Trail Lens with Baja Amber tint for dust, fog, rain, and snow conditions
- uService® technology — replaceable lenses and optics for easy maintenance
- ClearView® optics delivering light into Zones 1, 2, and 4
- Built-in over-voltage protection
- Backed by Baja Designs' 30-day satisfaction guarantee and limited lifetime warranty
Designed for Jeep JK Wrangler owners who spend time in low range on technical terrain, the S1 Knuckle Pods Light Kit provides near- and mid-field visibility exactly where it's needed most. The compact 2.1-inch S1 housing keeps the install clean and out of the way, while delivering big-light performance in a rugged, weather-sealed package.
