FASS INDPUIM165G Industrial Series Plus Diesel Fuel System Class UIM - 8 165GPH

Manufacturer

Part Number

INDPUIM165G
Black Friday Price

$819.00

Estimated ship date Friday, December 04

Authorize Seller Badge
No Hassle Returns

No Hassle Returns

Live-in-stock inventory

Live-in-stock inventory

Fitment guaranteed

Fitment guaranteed

Product Details

The FASS INDPUIM165G Industrial Series Plus Diesel Fuel System is a high-performance fuel air separation system engineered specifically for Class 8 semi-trucks equipped with Mechanical Unit Injection (UIM) fuel systems. Rated at 165 gallons per hour (GPH) at 16–18 PSI and proudly manufactured in the USA, this system is backed by FASS's industry-leading 1 million mile / 5-year warranty.

Designed to protect your injection system and extend injector life, the Industrial Series Plus delivers advanced multi-stage filtration with a combination of water separation and air/vapor removal technology. The system connects the FASS air separation port directly to the OEM engine fuel return line, eliminating the need for additional fuel return line installation and reducing installation time by up to 50%.

UIM-Specific Design: This kit is specifically engineered for engines with Mechanical Unit Injection. It includes an oil pressure switch that allows the FASS system to operate only when the engine is cranking or running, preventing fuel from being pumped through injectors into cylinders when the engine is off.

Key Features:

  • Flow Rate: 165 GPH at 16–18 PSI — supports diesel engines up to 600 HP
  • 2-Micron Absolute Filtration — superior protection against dirt, rust, and particulate contamination
  • FASS Extreme Water Separator — removes over 99% of water from diesel fuel; maintains high efficiency even at increased flow rates
  • Patented Air/Vapor Removal — FASS's exclusive process eliminates entrained air and vapor before fuel reaches the injectors
  • FASS Silencing Technology (FST) — radius cuts, precision gear tolerances, and military-spec coating over aluminum base for ultra-quiet operation
  • Performance Radius Cuts (PRC) — smooth-flowing machined cuts within the aluminum housing prevent air/vapor reintroduction and stagnant fuel pockets
  • Continuous Fuel Polishing (CFP) — repeatedly recirculates fuel through the Extreme Water Separator before delivery to the injection system for maximum fuel purity
  • Includes Oil Pressure Switch — required safety feature for UIM engine applications
  • No Dedicated Return Line Required — hooks up to the factory fuel return line for simplified installation
  • Made in the USA — assembled and tested with American-made components
  • Motor Failure Rate Under 2% — proven reliability through FASS engineering excellence

The FASS INDPUIM165G is the ideal heavy-duty diesel fuel lift pump upgrade for Class 8 commercial applications running mechanical unit injection engines, including select Cummins configurations. California Residents: WARNING — This product can expose you to chemicals known to the State of California to cause cancer. See www.P65Warnings.ca.gov for more information.
