Turbosmart TS-1-7675CP-VB096E TS-1 Pro Turbocharger 7675 V-Band 0.96AR Externally Wastegated

Manufacturer

Part Number

TS-1-7675CP-VB096E
Black Friday Price

$2,738.72

Estimated ship date Friday, December 04

Authorize Seller Badge
No Hassle Returns

No Hassle Returns

Live-in-stock inventory

Live-in-stock inventory

Fitment guaranteed

Fitment guaranteed

Product Details

The Turbosmart TS-1-7675CP-VB096E is a high-performance, externally wastegated turbocharger engineered for serious motorsport and performance applications. Part of Turbosmart's acclaimed TS-1 Pro series, this 7675 unit features a V-Band inlet and outlet configuration with a 0.96 A/R turbine housing, rated for an impressive 1,100–1,290 horsepower.

The TS-1 series is built around modern materials and advanced manufacturing techniques, resulting in a unit that is smaller, lighter, and faster-spooling than traditional turbocharger designs. The oil-cooled center section uses a proprietary dual ceramic bearing system and a low-rotating-mass shaft assembly paired with aggressive 7+7 split compressor wheel aerodynamics — delivering exceptional transient response and strong power output across a wide RPM range.

Key Features:

  • 76mm compressor inducer with 4" / 101.6mm compressor inlet
  • 75mm turbine exducer with V-Band 3.00" turbine inlet
  • 0.96 A/R turbine housing with 3.50" V-Band turbine outlet
  • 713C Inconel turbine wheel for extreme exhaust gas temperature resistance
  • 7+7 splitter compressor wheel machined from 2618 aluminum for aggressive aerodynamics
  • Lightweight 310S stainless steel investment cast turbine housing
  • Lightweight aluminum compressor cover with CFD-optimized housing design
  • Proprietary dual ceramic bearing system for ultra-low rotating mass
  • VSR speed balanced for reliability and precision
  • Integrated iron backplate on center housing
  • Externally wastegated design for precise boost control
  • Horsepower rating: 1,100–1,290 HP
  • Weight: 20.23 lbs (9.63 kg)

What's Included:

  • Turbocharger assembly
  • Weld flanges
  • V-Band clamps
  • Gaskets
  • Oil feed and drain fittings

Designed with an engine end-to-end approach, every component works together to reduce back pressure and maximize turbine efficiency — making the Turbosmart TS-1 Pro 7675 an ideal choice for high-horsepower builds demanding reliability, response, and race-proven performance.
