ACT T3RS-N04 Mod-Twin 225 Max Extreme Sprung Race Clutch Kit

Manufacturer

Part Number

T3RS-N04
Black Friday Price

$1,728.01

Estimated ship date Friday, December 04

Authorize Seller Badge
No Hassle Returns

No Hassle Returns

Live-in-stock inventory

Live-in-stock inventory

Fitment guaranteed

Fitment guaranteed

Product Details

The ACT T3RS-N04 Mod-Twin 225 Max Extreme (XX) Sprung Race Clutch Kit is a high-performance twin disc clutch system engineered for demanding race and high-powered AWD applications. Combining twice the ceramic friction surfaces with ACT's ultra-durable Mono-Drive sprung hub assembly in a completely modular design, this kit delivers the aggressive launch capability and rapid, smooth shifting that serious motorsport demands.

Each diaphragm spring undergoes ACT's exclusive four-stage heat treating process, delivering a consistent pedal feel with moderate effort. Puck-style ceramic friction plates provide a high friction coefficient, superior heat capacity, and extended clutch life. These friction plates uniformly transfer torque through the Mono-Drive sprung hub assembly, protecting the input shaft and absorbing driveline shock caused by torsional vibration.

Key Features:

  • Dual ceramic puck-style friction plates for maximum torque capacity and heat resistance
  • Mono-Drive sprung hub assembly reduces driveline shock and extends input shaft life
  • Four-stage heat-treated diaphragm spring for consistent, moderate pedal feel
  • CNC-machined and dynamically balanced flywheel for smooth operation across the full RPM range
  • Patented Monoloc Collar included for secure assembly
  • Fully modular and rebuildable design — most components available for individual replacement
  • Computer spin balanced to within 0.25 oz-in for vibration-free performance

Kit Includes: CNC-machined and dynamically balanced flywheel, pressure plate cover, diaphragm spring, face, puck-style ceramic friction plates, sprung Mono-Drive hub assembly, floater, patented Monoloc Collar, release bearing, alignment tool, and pilot bearing (if needed).

The ACT Mod-Twin series is fully rebuildable, and most components can be ordered separately, making it a cost-effective long-term performance investment for high-powered AWD builds.

Products specifications

Product Weight (lbs.)

29.5

SFI

1.2

Torque Capacity Over OE

232%

Prop 65

WARNING: Cancer and Reproductive Harm - www.p65warnings.ca.gov
Warning: This product can expose you to chemicals including carbon black, glass wool fibers, or silica (in clutch discs), chromium and nickel, which are known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit www.P65Warnings.ca.gov

Torque Capacity (ft/lbs.)

1340
