ACT T2SS-N04 Mod-Twin 225 XT Sprung Street Twin Disc Clutch Kit

The ACT T2SS-N04 Mod-Twin 225 XT Sprung Street Clutch Kit is engineered for high-powered AWD street cars demanding maximum torque capacity without sacrificing daily drivability. By combining twice the organic friction surfaces with an ultra-durable sprung-center Mono-Drive hub in a fully modular design, this twin disc clutch kit delivers exceptional torque holding, smooth engagement, and a street-friendly pedal feel.

Each diaphragm spring undergoes ACT's exclusive four-stage heat treating process, ensuring a consistent, light pedal effort over the life of the clutch. Steel-backed Friction Plates with premium organic friction materials provide a stable friction coefficient, excellent heat capacity, and long service life. Torque is uniformly transferred through the Mono-Drive sprung hub assembly, which helps reduce driveline shock from torsional vibration and extends input shaft life.

Kit Includes:

• CNC-machined and dynamically balanced flywheel
• Pressure plate cover and diaphragm spring
• Puck-style ceramic and organic friction plates
• Sprung Mono-Drive hub assembly
• Floater plate
• Patented Monoloc Collar
• Release bearing
• Alignment tool
• Pilot bearing (if applicable)

Key Features:

• Dual-disc design doubles friction surface area for very high torque capacity
• Sprung Mono-Drive hub absorbs driveline shock and reduces torsional vibration
• Four-stage heat-treated diaphragm springs for consistent, light pedal feel
• Computer spin balanced to within 0.25 oz-in for smooth operation across the full RPM range
• Fully modular and rebuildable — most components available individually
• 225mm clutch diameter

The Mod-Twin's fully rebuildable, modular architecture means individual components can be replaced as needed, making long-term ownership cost-effective. ACT part number: T2SS-N04.
