ACT T1SS-N04 Mod-Twin 225 Heavy Duty Sprung Street Twin-Disc Clutch Kit

The ACT T1SS-N04 is a Mod-Twin 225 Heavy Duty Sprung Street Clutch Kit engineered for high-powered Nissan applications demanding very high torque capacity without sacrificing street drivability. ACT's Mod-Twin platform addresses the common tradeoffs found on traditional twin-disc clutches by delivering an ultra-durable, fully modular design with uncompromised pedal feel and progressive engagement characteristics.

At the core of this system is ACT's sprung Mono-Drive hub assembly, which uniformly distributes torque across both friction surfaces while absorbing driveline shock from torsional vibration — extending input shaft life compared to rigid hub designs. Steel-backed friction plates with premium organic friction materials ensure a stable friction coefficient, excellent heat capacity, and long service life. Each diaphragm spring undergoes an exclusive four-stage heat-treating process to deliver consistent, light pedal feel across the RPM range.

Key Features:

• Dual-disc design doubles organic friction surfaces for very high torque capacity
• Sprung Mono-Drive hub assembly reduces driveline shock and protects the input shaft
• CNC-machined and dynamically balanced flywheel for trouble-free installation and smooth operation
• ACT proprietary Adjustable Positive Lift Floater — quiet operation with no floater rattle and no posts to wear out
• Patented Monoloc Collar for secure, precise assembly
• All assemblies computer spin-balanced to within 0.25 oz-in (vs. 0.50 oz-in for stock clutches)
• Heavy Duty clamp load provides approximately 15–40% increase in pedal effort over stock
• Fully rebuildable — most components available separately for cost-effective long-term ownership
• SFI certified for safety in performance applications

Kit Includes: CNC-machined dynamically balanced flywheel, pressure plate cover, diaphragm spring, face plates, puck-style ceramic friction plates, sprung Mono-Drive hub assembly, floater, patented Monoloc Collar, release bearing, alignment tool, and pilot bearing (if required).

The ACT T1SS-N04 Mod-Twin clutch kit is designed for street and street/strip use on high-powered Nissan vehicles. Its completely modular construction makes it one of the most serviceable performance twin-disc clutch systems available, ensuring lasting performance well beyond a standard clutch's service life.
