Diode Dynamics DD8882 HitchMount LED Pod Reverse Light Kit for GMC Canyon, C1R

(2023-2026 GMC Canyon)

Manufacturer

Part Number

DD8882
Black Friday Price

$174.02

2 left at this price

delivery box

Usually delivered within 2 days

free shipping

FREE SHIPPING

Authorize Seller Badge
No Hassle Returns

No Hassle Returns

Live-in-stock inventory

Live-in-stock inventory

Fitment guaranteed

Fitment guaranteed

Product Details

The Diode Dynamics DD8882 HitchMount LED Pod Reverse Light Kit is a vehicle-specific lighting upgrade designed for 2023–2026 GMC Canyon trucks. It mounts a C1R LED pod directly into the trailer hitch receiver, delivering a dramatically brighter reverse light alongside an additional running light and optional 4th brake light — all without any drilling, custom wiring, or routing wires through the vehicle. The included wiring harness plugs into factory connectors under the bumper for a clean, seamless integration.

The C1R pod pairs high-powered LEDs with Diode Dynamics' patented TIR (Total Internal Reflection) optic, which collects and focuses all available light onto the target area rather than losing it to glare or internal scatter. The result is 1,080 lumens of output at a 6000K color temperature with an 80°×50° flood beam — several times brighter than a stock reverse bulb. The housing is constructed of steel with a clear polycarbonate lens and carries an IP69K waterproof rating, handling high-pressure wash-down and extreme temperatures from -40°F to 185°F. Optional SafetyStrobe functionality adds brake light strobing capability with the C1R.

Key Features:

  • Mounts one C1R LED pod into any 2-inch or 2.5-inch trailer hitch receiver on the GMC Canyon
  • Adds a high-power reverse light, additional running light, and optional 4th brake light
  • Patent-pending snap-fit design — no drilling, no hitch pin required; installs in under 5 minutes
  • Patented TIR optic focuses light output and reduces glare for maximum efficiency
  • 1,080 measured lumens, 6000K color temperature, 80°×50° flood beam angle
  • 480 lux intensity; 14.1-watt draw; operates on 9–16V
  • IP69K waterproof rating; operating range -40°C to 85°C (-40°F to 185°F)
  • Steel housing with clear polycarbonate lens
  • Wiring harness included; connects to factory vehicle connectors
  • Optional SafetyStrobe brake light strobing
  • Designed and assembled in the USA

This kit is a direct-fit solution for select 2023–2026 GMC Canyon models. Each purchase includes one C1R HitchMount LED Pod, one snap-in 2.5-inch receiver adapter, one vehicle-specific wiring harness, three zip ties, and an installation guide. Note: this kit is not DOT approved for on-road forward-facing use; confirm local regulations for auxiliary reverse lighting.

Products specifications

Fits

2023-2026 GMC Canyon
