Clutch Masters 06028-TD8R-1AW FX850 Twin Disc Race Clutch Kit 8.5in

Manufacturer

Part Number

06028-TD8R-1AW
Black Friday Price

$2,326.50

Estimated ship date Friday, December 04

Authorize Seller Badge
No Hassle Returns

No Hassle Returns

Live-in-stock inventory

Live-in-stock inventory

Fitment guaranteed

Fitment guaranteed

Product Details

The Clutch Masters FX850 Twin Disc Race Clutch Kit (06028-TD8R-1AW) is an 8.5-inch (216mm) twin disc performance clutch system engineered for high-horsepower applications where maximum clamping force and durability are non-negotiable. Designed as pure racing technology, it is also suitable for high-performance street applications used on the track with occasional street use.

The TD8R "Race" configuration pairs one sprung ceramic disc with one ceramic rigid disc, delivering aggressive engagement characteristics optimized for high-RPM staging and competition driving. By increasing both the clamping force of the pressure plate and the total square inches of usable disc area, the FX850 Twin Disc delivers an average of 50% increase in clamping values compared to a single-disc setup, depending on the application.

Key Features:

  • 8.5-inch (216mm) twin disc design — maximizes torque capacity for smaller bellhousing applications
  • TD8R Race friction pairing — 1 sprung ceramic disc + 1 ceramic rigid disc for aggressive, precise engagement
  • Billet aluminum cover assembly — machined for 25% greater tensile strength versus competing cast units, then Type 3 hard anodized for durability
  • QR Quick Release Pressure Plate system — three spring-loaded bolts enable smooth, even engagement/disengagement while reducing clutch noise and chatter by up to 50%
  • Positive release design — optimized for high-RPM staging and fast shifts
  • Serviceable components — all parts available separately for cost-effective repair and rebuild
  • Manufactured in the USA — Clutch Masters controls the full design-to-assembly process

Kit Includes:

  • Aluminum cover assembly with attached diaphragm
  • Pressure plate ring
  • Two friction discs (1 sprung ceramic + 1 ceramic rigid)
  • One mid plate
  • Release bearing
  • Pilot bearing (where applicable)
  • Pressure plate bolts

Note: Flywheel may be sold separately depending on application. Verify flywheel compatibility with the CM flywheel requirement for this specific MPN before ordering. All components are available individually for economical future servicing.

Products specifications

Flywheel Bolts Included

No

Flywheel Material

Aluminum

Alignment Tool Included

Yes

Release Bearing Included

YES

Flywheel Included

Yes

Pressure Plate Bolts Included

Yes

Pilot Bearing Included

No

Disc Material

Dual Ceramic

Disc Type

Sprung

Pressure Plate

8.50" Billet Aluminum Cover (Pull)

Torque Capacity Rating

800 ft.lbs
