Baja Designs 55-7801-2NH Squadron 2.0 Sport LED Spot Light Pod Pair No Harness

Manufacturer

Part Number

55-7801-2NH
Black Friday Price

$249.95

3 left at this price

delivery box

Usually delivered within 2 days

free shipping

FREE SHIPPING

Authorize Seller Badge
No Hassle Returns

No Hassle Returns

Live-in-stock inventory

Live-in-stock inventory

Fitment guaranteed

Fitment guaranteed

Product Details

The Baja Designs Squadron 2.0 Sport is the next generation of Baja Designs' most popular compact LED pod, now delivering a 26% performance increase over the original Squadron Sport 1.0. This pair ships without a wiring harness, making it ideal for builders integrating into existing wiring, custom harness setups, or upfitter circuits. The lights feature 4-Pin Deutsch connectors fully compatible with Baja Designs harnesses sold separately.

Each light produces 3,200 lumens at 30 watts in a compact 3-inch housing. The Spot beam pattern delivers a narrow 9° focused beam for maximum illumination distance down the trail or road, designed to work in conjunction with Wide Driving or Driving/Combo lights for complete coverage.

What's New in 2.0:

  • RGBW Backlight — All-new integrated backlight with 9 selectable colors
  • Updated Spot Optics — Redesigned lens pattern for improved beam performance and reduced spill
  • Redesigned Universal Bracket — Increased vertical light adjustment range
  • Improved uService Ability — New clip-in reflectors retained during lens changes; new gaskets eliminate pinched O-rings for better element protection
  • Mounting Pocket Nuts — Improved reliability and eliminate stripped housings

Key Features:

  • 3,200 lumens per light using 4 LEDs at 30W
  • 5,000K daylight color temperature — reduces driver fatigue with natural color rendering
  • IP69K rated — waterproof, rain-proof, and submersible to 9 feet
  • IK10 Compliant — mechanical impact tested
  • Exceeds MIL-STD-810G military-spec testing (temperature, humidity, vibration, dust, shock)
  • Built-in overvoltage protection
  • Hard coated polycarbonate front lens
  • Powder coated cast aluminum housing
  • Billet machined aluminum bezel
  • Stainless steel hardware and bracket material
  • LED life expectancy: 49,930+ hours
  • Operates on 12–36V DC
  • CopperDrive® — LEDs driven at 100% for maximum output
  • MoistureBlock™ — fully sealed weatherproof construction

What's Included:

  • (2) Baja Designs Squadron 2.0 Sport LED Spot Lights
  • (2) Universal Adjustable Mounting Brackets
  • (2) Mounting Hardware Sets
  • No wiring harness — harness sold separately

Backed by Baja Designs' industry-first 30-Day Satisfaction Guarantee and Limited Lifetime Warranty. Old part number reference: 55-7801.

Products specifications

Prop 65

Prop 65 WARNING: This product can expose you to chemicals, which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.

Description

Backlight: 9-Colors

Length (in.)

2.84”

Voltage

Operating White Light Voltage: 10–36V; Operating Backlight Voltage: 11-14V

Height (in.)

3.29”

DES

Squadron 2.0 Sport Black LED Auxiliary Light Pod Pair (No Harness)

EXT

Squadron 2.0 Sport Black LED Auxiliary Light Pod Pair (No Harness) (Spot; Clear)

TLE

Squadron 2.0 Sport Black LED Auxiliary Light Pod Pair (No Harness) (Spot; Clear)

Amperage Rating (A)

30W / 2.2A @ 13.8V

Brightness (Lumens)

3,200 lm

Depth (in.)

3.32”

Standards/Compliance (Water Resistance)

IP69K

Terminal Connector

Deutsch
