The APR KT100043 is a complete ignition coil and spark plug kit engineered for 3.0T EA837 6-cylinder engines. This kit bundles six APR MS100208 Red Ignition Coils with six APR Z1003101 Iridium Pro Spark Plugs (Heat Range 9), delivering a comprehensive ignition system refresh in a single package. Both components are purpose-built to work together for a stronger, more consistent spark across all six cylinders.
The APR MS100208 ignition coils are a direct plug-and-play upgrade over factory coils, producing up to 10% more energy output than stock. Featuring a distinctive red housing, these coils are direct replacements for OEM part numbers including 06D905115A/C/D/F/G/K, 06E905115A/B/C/D/E/F/G, 06F905115C/E/F, 06H905611, 06H905115/B, 06L905110B, and 07K905715D/E/F/G.
The APR Z1003101 Iridium Pro Spark Plugs feature a Heat Range 9 cold plug design with a copper core and iridium electrode. Their high-heat dispersal construction helps regulate combustion temperatures for consistent performance under extreme conditions, including high-boost, high-cylinder-pressure, and high-power applications. Direct replacements for OEM part numbers 06H905601A, 06Q905601E, and 101905631G.
Spark Plug Specifications:
- Thread Diameter: 14mm
- Thread Reach: 19mm
- Hexagon: 16mm
- Seat Type: Gasket
- Install Torque: 25 Nm
- Heat Range: 9 (cold plug)
- Made in the EU
Kit Contents:
- 6x APR MS100208 Ignition Coils — Red (PQ35/PQ45 platform style)
- 6x APR Z1003101 Iridium Pro Spark Plugs — Heat Range 9
Key Features:
- Up to 10% greater energy output over stock ignition coils
- Iridium electrode with copper core for superior heat dissipation and durability
- Direct plug-and-play fitment — no modifications required
- Engineered to work together for maximized ignition performance
- Suitable for stock and tuned engines running higher boost or power upgrades
- Coil OEM cross-references: 06D905115A/C/D/F/G/K, 06E905115A/B/C/D/E/F/G, 06H905611, 06L905110B
- Spark plug OEM cross-references: 06H905601A, 06Q905601E, 101905631G
This product is legal under the provisions of the EPA's Tampering Policy. Note: This product is NOT LEGAL FOR SALE OR USE IN THE STATE OF CALIFORNIA. Testing with the California Air Resources Board (CARB) is pending for 50-state compliance.
