Diode Dynamics DD8627 SS6 Stage Series LED Light Bar Grille Kit — Pair, Yellow Driving

The Diode Dynamics DD8627 Stage Series SS6 LED Light Bar Grille Kit delivers a pair of 6-inch LED light bars purpose-built for grille-mount installation. Engineered from the ground up with patented TIR (Total Internal Reflection) optics, each bar maximizes light output and efficiency in a compact form factor. The 3000K yellow driving beam produces 7,920 raw lumens at 71,000 lux with a focused 20°×12° SAE Driving beam pattern fine-tuned for real-world conditions. An IP69K waterproof rating means these bars stand up to high-pressure washdowns and harsh environments, and an operating range of -40°F to 185°F ensures reliable performance in any climate. The 40.5-watt pair runs on 9–30V, making them compatible with 12V and 24V electrical systems.

Key Features:

• Patented TIR optics for maximum efficiency and light output
• 7,920 raw lumens, 71,000 lux intensity — 3000K yellow driving beam
• 20°×12° SAE Driving beam pattern optimized for real-world use
• True amber backlight provides unique accent lighting
• IP69K waterproof rating — withstands high-pressure washing
• Operating temperature: -40°F to 185°F (-40°C to 85°C)
• 9–30V input voltage; 40.5 watts total
• Available in Sport, Pro, and Max power levels
• CAD-designed application-specific brackets use factory mounting points — no cutting or drilling required
• Includes both left and right side light bars (sold as a pair)

This kit is designed for a clean, integrated appearance in the grille opening, with brackets engineered specifically for the application to ensure a precise, factory-quality fit. Fits select 2019–2021 Ford Ranger models. California Proposition 65 Warning: Cancer and Reproductive Harm — www.P65Warnings.ca.gov.
