Turbosmart TS-2-5862B-T4082E-RR TS-2 Water-Cooled Turbocharger 5862 T4 Reverse Rotation 0.82AR Externally Wastegated

Manufacturer

Part Number

TS-2-5862B-T4082E-RR
Black Friday Price

$2,150.99

Estimated ship date Wednesday, December 02

Authorize Seller Badge
No Hassle Returns

No Hassle Returns

Live-in-stock inventory

Live-in-stock inventory

Fitment guaranteed

Fitment guaranteed

Product Details

The Turbosmart TS-2-5862B-T4082E-RR is a water and oil-cooled performance turbocharger featuring a 58mm compressor inducer, 62mm turbine exducer, T4 inlet flange, 0.82 A/R turbine housing, and reverse rotation configuration with external wastegate outlet. Rated to support 725–835 horsepower, this unit is purpose-built for demanding motorsport and high-performance street builds requiring reverse-rotation turbo placement.

The TS-2 series is engineered around ultra-low rotating mass, pairing a proprietary dual ceramic bearing system and main shaft assembly with aggressive compressor aerodynamics for exceptional transient response and strong output at lower shaft speeds. The turbine housing is constructed from lightweight 310S stainless steel investment casting, while the compressor cover uses lightweight aluminum for overall weight reduction. The turbine wheel is manufactured from 713C Inconel for durability under extreme exhaust gas temperatures. All rotating assemblies are VSR speed balanced for reliability and long-term durability.

Key Features:

  • Reverse rotation design for twin-turbo and custom manifold applications
  • Water and oil-cooled center housing for enhanced thermal management
  • T4 inlet flange with V-Band turbine outlet (3.00")
  • 0.82 A/R turbine housing — 725–835HP rated
  • 7+7 2618 aluminum splitter compressor wheel
  • 713C Inconel turbine wheel for extreme EGT resistance
  • Lightweight 310S stainless steel investment cast turbine housing
  • Proprietary dual ceramic bearing system
  • CFD-optimized housing for peak flow and A/R efficiency
  • Integrated iron backplate on center housing
  • VSR speed balanced for precision and reliability

Specifications:

  • Compressor Inlet: 4" / 101.6mm
  • Compressor Inducer: 58mm
  • Turbine Inlet: T4 Flange
  • Turbine Exducer: 62mm
  • Turbine A/R: 0.82
  • Turbine Outlet: V-Band (3.00")
  • Weight: 13.3 lbs (6.06 kg)
  • Horsepower Rating: 725–835HP

What's Included:

  • 1x Turbosmart TS-2 Performance Turbocharger
  • 2x Weld Flanges (Turbine Inlet and Outlet)
  • 2x V-Band Clamps (Turbine Inlet and Outlet)
  • Gaskets, oil feed and drain fittings
  • Water feed and return fittings
