Manley 648205C-8 Platinum Series Engine Piston Set — Toyota 5.7L 3UR-FE 94.5mm +0.50mm Overbore

Manufacturer

Part Number

648205C-8
Black Friday Price

$1,482.36

1 left at this price

delivery box

Usually delivered within 2 days

free shipping

FREE SHIPPING

Authorize Seller Badge
No Hassle Returns

No Hassle Returns

Live-in-stock inventory

Live-in-stock inventory

Fitment guaranteed

Fitment guaranteed

Product Details

The Manley 648205C-8 is a Platinum Series forged engine piston set designed for the Toyota 5.7L 3UR-FE engine. Each piston features a dish-top design with a -24cc piston volume, yielding an 11.00:1 compression ratio at the stock 102mm stroke. The bore diameter is 94.50mm (+0.50mm oversize), making this set suitable for cylinder bores that have been bored or honed 0.50mm over standard. Compression height is 1.328 inches, and each piston weighs 396 grams.

Key Features:

  • 2618 Alloy Forgings: Domestically sourced 2618 alloy provides superior strength and durability for street and performance applications
  • Chrome Moly Wrist Pins: Premium chrome moly wrist pins are included as standard; select SKUs offer upgrades to 9310 or Turbo Tuff/DLC alloys for additional durability
  • Exacting Ring Lands and Grooves: Precision-machined ring lands and grooves deliver enhanced ring seal and consistent power output
  • Cam and Barrel Skirt Profiles: Optimized skirt geometry generates strong power while minimizing cylinder wall wear
  • Single-Operation Skirt and Ring Groove Machining: Manley's unique fixturing machines the skirt and ring grooves in one operation, ensuring maximum ring groove-to-skirt squareness
  • Piston Series: Platinum Series — Standard Sub-Series
  • Quantity: 8 pistons per set
  • Compression Ratio: 11.00:1
  • Bore Diameter: 94.50mm (+0.50mm oversize)
  • Compression Height: 1.328 in
  • Piston Volume: -24cc (dish)
  • Engine Stroke: 102.00mm (stock)
  • Piston Weight: 396 grams each

Trusted by professional engine builders and performance tuners, Manley's Platinum Series pistons deliver the precision and reliability demanded by high-output builds. This set is designed for the Toyota 5.7L 3UR-FE engine with a +0.50mm overbore. Verify your cylinder bore measurements against the 94.50mm specification before installation.

Products specifications

Piston Quantity

8

Weight

396

Make

Toyota

Piston Head Type

Dish

Engine Type

ICE

Product Type

Engine Piston Kit

Piston Volume

-24.00

Bore Diameter

94.50

Piston Series

Platinum Series

Piston Sub-Series

Standard

Engine Stroke Type

Stock

Bore Oversize

+0.50

Compression Ratio

11.00:1

Compression Height

1.328

Engine

5.7L 3UR-FE

Engine Stroke

102.00

Title

Manley Piston Set, PIST-TOYOTA 5.7L 3UR-FE 94.5mm -24cc
